Overview
The LPC2106FHN48/01 is a 32-bit microcontroller from NXP USA Inc., part of the LPC2100 series. This microcontroller is based on the ARM7TDMI-S core, which provides a balance between performance and power efficiency. It is designed for a wide range of applications, including industrial control, medical devices, and consumer electronics. The LPC2106FHN48/01 is packaged in a 48-pin HVQFN (Heat-sink Very Thin Quad Flat No-leads) package, making it suitable for space-constrained designs.
Key Specifications
| Parameter | Description |
|---|---|
| Core Processor | ARM7TDMI-S |
| Core Size | 16/32-bit |
| Flash Memory | 128 KB |
| Package Type | 48-pin HVQFN |
| External Memory Controller | No |
| Graphics Controller | No |
| Operating Voltage | 3.0V to 3.6V |
| Operating Temperature | -40°C to 85°C |
| Compliance | RoHS, ELV, China RoHS compliant |
Key Features
- ARM7TDMI-S Core: High-performance 16/32-bit RISC CPU with a maximum clock frequency of up to 70 MHz.
- Memory: 128 KB of on-chip flash memory and 16 KB of SRAM.
- Peripheral Set: Includes UARTs, SPI, I2C, I2S, and a 10-bit ADC.
- Low Power Consumption: Optimized for low power consumption, making it suitable for battery-powered devices.
- Package Options: Available in 48-pin HVQFN package, which is lead-free and RoHS compliant.
- Development Support: Supported by a range of development tools and software, including the Keil µVision development environment.
Applications
- Industrial Control: Suitable for industrial automation, motor control, and other industrial applications.
- Medical Devices: Used in medical devices such as patient monitoring systems and diagnostic equipment.
- Consumer Electronics: Found in consumer electronics like audio equipment, set-top boxes, and gaming consoles.
- Automotive Systems: Used in various automotive systems, including infotainment and safety systems.
- Internet of Things (IoT): Ideal for IoT applications requiring low power consumption and high performance.
Q & A
- What is the core processor of the LPC2106FHN48/01?
The core processor is the ARM7TDMI-S.
- How much flash memory does the LPC2106FHN48/01 have?
The LPC2106FHN48/01 has 128 KB of on-chip flash memory.
- What is the package type of the LPC2106FHN48/01?
The package type is 48-pin HVQFN.
- Is the LPC2106FHN48/01 RoHS compliant?
Yes, the LPC2106FHN48/01 is RoHS, ELV, and China RoHS compliant.
- What is the operating voltage range of the LPC2106FHN48/01?
The operating voltage range is 3.0V to 3.6V.
- What are some of the peripherals included in the LPC2106FHN48/01?
The peripherals include UARTs, SPI, I2C, I2S, and a 10-bit ADC.
- What development tools support the LPC2106FHN48/01?
It is supported by tools such as the Keil µVision development environment.
- What are some common applications of the LPC2106FHN48/01?
Common applications include industrial control, medical devices, consumer electronics, automotive systems, and IoT devices.
- What is the maximum clock frequency of the LPC2106FHN48/01?
The maximum clock frequency is up to 70 MHz.
- How much SRAM does the LPC2106FHN48/01 have?
The LPC2106FHN48/01 has 16 KB of SRAM.
