Overview
The LPC1111FDH20/002518 is a 32-bit microcontroller from NXP USA Inc., part of the LPC1100 series. This microcontroller is based on the ARM Cortex-M0+ core, which provides a high level of performance and efficiency. It is designed for a wide range of applications, including industrial control, consumer electronics, and IoT devices. The LPC1111FDH20/002518 is known for its low power consumption and compact package, making it an ideal choice for space-constrained and power-sensitive designs.
Key Specifications
| Parameter | Value |
|---|---|
| Core Processor | ARM Cortex-M0+ |
| Core Size | 32-Bit Single-Core |
| Speed | 30MHz |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| RAM Size | 4K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 20 |
| Operating Temperature | -40 ℃ ~ 105 ℃ (TA) |
| Package / Case | 20-TSSOP |
| Mounting Type | Surface Mount |
| Environmental Compliance | RoHS Compliant, Lead Free, No SVHC |
Key Features
- ARM Cortex-M0+ Core: Provides high performance and low power consumption.
- Compact Package: 20-TSSOP package suitable for space-constrained designs.
- Low Power Consumption: Ideal for battery-powered and power-sensitive applications.
- Peripheral Set: Includes brown-out detect/reset, POR, PWM, and WDT for robust system design.
- Communication Interfaces: Supports I2C, SPI, and UART/USART for versatile communication needs.
- Wide Operating Temperature Range: Operates from -40 ℃ to 105 ℃, making it suitable for various environmental conditions.
Applications
- Industrial Control: Suitable for control systems, sensors, and actuators in industrial settings.
- Consumer Electronics: Used in devices such as smart home appliances, wearables, and handheld devices.
- IoT Devices: Ideal for Internet of Things applications requiring low power and compact design.
- Automotive Systems: Can be used in automotive control systems and accessories.
- Medical Devices: Suitable for medical devices that require low power consumption and reliability.
Q & A
- What is the core processor of the LPC1111FDH20/002518?
The core processor is the ARM Cortex-M0+. - What is the maximum operating frequency of the LPC1111FDH20/002518?
The maximum operating frequency is 30MHz. - How much program memory does the LPC1111FDH20/002518 have?
The LPC1111FDH20/002518 has 8KB of FLASH program memory. - What is the RAM size of the LPC1111FDH20/002518?
The RAM size is 4K x 8. - What are the supported communication interfaces?
The supported interfaces include I2C, SPI, and UART/USART. - What is the operating temperature range of the LPC1111FDH20/002518?
The operating temperature range is -40 ℃ to 105 ℃. - Is the LPC1111FDH20/002518 RoHS compliant?
Yes, the LPC1111FDH20/002518 is RoHS compliant and lead-free. - What is the package type of the LPC1111FDH20/002518?
The package type is 20-TSSOP. - What are some of the peripherals included in the LPC1111FDH20/002518?
The peripherals include brown-out detect/reset, POR, PWM, and WDT. - How many I/O pins does the LPC1111FDH20/002518 have?
The LPC1111FDH20/002518 has 20 I/O pins.
