Overview
The 74LVC1G32GW/S400125 is a single 2-input OR gate from the LVC (Low Voltage CMOS) series, manufactured by NXP USA Inc. This component is part of the broader family of logic gates and inverters, designed to operate at low voltages while maintaining high performance and low power consumption.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | 74LVC1G32GW/S400125 |
| Manufacturer | NXP USA Inc. |
| Description | OR Gate, LVC/LCX/Z Series |
| Package Type | PDSO5 (SOT353) |
| Number of Inputs | 2 |
| Number of Outputs | 1 |
| Supply Voltage Range | 1.65 V to 5.5 V |
| Operating Temperature Range | -40°C to +125°C |
| RoHS Compliance | Yes |
Key Features
- Low voltage CMOS technology, compatible with JEDEC JESD8-7 standard.
- Wide supply voltage range from 1.65 V to 5.5 V.
- High-speed operation with short propagation delays.
- Low power consumption.
- ESD protection exceeds JESD22 standards.
- Lead-free and RoHS compliant.
Applications
The 74LVC1G32GW/S400125 is suitable for a variety of applications where low voltage and high-speed logic operations are required. These include:
- Mobile devices and portable electronics.
- Automotive systems.
- Industrial control systems.
- Consumer electronics.
- Communication devices.
Q & A
- What is the primary function of the 74LVC1G32GW/S400125?
The primary function is to act as a single 2-input OR gate. - What is the supply voltage range for this component?
The supply voltage range is from 1.65 V to 5.5 V. - Is the 74LVC1G32GW/S400125 RoHS compliant?
Yes, it is RoHS compliant. - What is the operating temperature range?
The operating temperature range is from -40°C to +125°C. - What package type does the 74LVC1G32GW/S400125 come in?
The package type is PDSO5 (SOT353). - What are the key features of the LVC series?
The key features include low voltage CMOS technology, wide supply voltage range, high-speed operation, low power consumption, and ESD protection. - Where can I find the datasheet for this component?
The datasheet can be found on the official NXP website or through authorized distributors like DigiPart or Mouser. - Is the 74LVC1G32GW/S400125 suitable for automotive applications?
Yes, it is suitable for automotive systems due to its robust specifications and compliance with automotive standards. - What are some common applications for this component?
Common applications include mobile devices, industrial control systems, consumer electronics, and communication devices. - How do I ensure the component is genuine?
Purchase from authorized distributors and check for certifications and markings on the component.
