Overview
The 74LVC4245AD-Q100J is an octal dual supply translating transceiver produced by Nexperia USA Inc. This integrated circuit is designed to facilitate communication between two different voltage domains, making it a crucial component in various electronic systems. It features non-inverting 3-state bus compatible outputs in both send and receive directions, ensuring seamless data transmission and reception across different voltage levels.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | 74LVC4245AD-Q100J |
| Manufacturer | Nexperia USA Inc. |
| Package Type | Tape & Reel (TR), SOIC-24 |
| Function | Octal Dual Supply Translating Transceiver |
| Output Type | 3-State, Non-Inverting |
| Voltage Range | 1.65 V to 5.5 V |
| Operating Temperature | -40°C to +125°C |
| Compliance | EU RoHS, REACH compliant |
Key Features
- Octal dual supply translating transceiver with non-inverting 3-state bus compatible outputs.
- Supports voltage translation between two different voltage domains.
- Operates over a wide voltage range from 1.65 V to 5.5 V.
- High-speed data transmission and reception capabilities.
- Compliant with EU RoHS and REACH regulations.
Applications
The 74LVC4245AD-Q100J is versatile and can be used in a variety of applications, including:
- Interface translation between different voltage domains in mixed-signal systems.
- Data communication in industrial control systems.
- Voltage level shifting in automotive electronics.
- Signal translation in medical devices.
- General-purpose logic translation in consumer electronics.
Q & A
- What is the primary function of the 74LVC4245AD-Q100J?
The primary function is to act as an octal dual supply translating transceiver, facilitating communication between two different voltage domains. - What package types are available for the 74LVC4245AD-Q100J?
The component is available in Tape & Reel (TR) and SOIC-24 packages. - What is the operating voltage range of the 74LVC4245AD-Q100J?
The operating voltage range is from 1.65 V to 5.5 V. - Is the 74LVC4245AD-Q100J compliant with EU RoHS and REACH regulations?
Yes, it is compliant with both EU RoHS and REACH regulations. - What are the typical applications of the 74LVC4245AD-Q100J?
Typical applications include interface translation, data communication in industrial control systems, voltage level shifting in automotive electronics, and general-purpose logic translation. - What is the operating temperature range of the 74LVC4245AD-Q100J?
The operating temperature range is from -40°C to +125°C. - Does the 74LVC4245AD-Q100J support 3-state outputs?
Yes, it supports 3-state bus compatible outputs in both send and receive directions. - Who is the manufacturer of the 74LVC4245AD-Q100J?
The manufacturer is Nexperia USA Inc. - What is the significance of the 'Q100' suffix in the part number?
The 'Q100' suffix indicates that the component is part of Nexperia's Q100 series, which is designed for automotive and industrial applications requiring high reliability. - Where can I find detailed specifications and datasheets for the 74LVC4245AD-Q100J?
Detailed specifications and datasheets can be found on the Nexperia website, as well as on distributor sites like Digi-Key and Viassion Electronics.
