Overview
The 74LVC138AD-Q100J is a low-voltage, low-power, high-performance Si-gate CMOS decoder/demultiplexer produced by Nexperia USA Inc. This device is part of the 74LVC series, known for its compatibility with advanced CMOS and TTL families. It operates as a 3-to-8 line decoder/demultiplexer, making it suitable for a variety of digital logic applications. The device is designed to be robust, with a wide operating temperature range and a single supply voltage from 1.2V to 3.6V, enhancing its versatility in different environments.
Key Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Nexperia USA Inc. |
| Part Number | 74LVC138AD-Q100J |
| Type | Decoder/Demultiplexer |
| Circuit | 1 x 3:8 |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 1.2V ~ 3.6V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Current - Output High, Low | 24mA, 24mA |
| RoHS | Yes |
Key Features
- Low-Voltage Operation: The device operates with a single supply voltage from 1.2V to 3.6V, making it suitable for low-power applications.
- High Performance: It is a high-performance Si-gate CMOS device, superior to most advanced CMOS compatible TTL families.
- Wide Operating Temperature Range: The device can operate in a temperature range from -40°C to 125°C, enhancing its reliability in various environments.
- Surface Mount Package: It comes in a 16-SOIC package, which is convenient for surface mount assembly.
- RoHS Compliant: The device is RoHS compliant, ensuring it meets environmental standards.
Applications
- Digital Logic Circuits: The 74LVC138AD-Q100J is ideal for use in digital logic circuits where decoding and demultiplexing functions are required.
- Automotive Systems: Given its AEC-Q100 qualification, it is suitable for use in automotive systems that require robust and reliable components.
- Industrial Control Systems: The device can be used in industrial control systems where high performance and reliability are crucial.
- Consumer Electronics: It can also be applied in various consumer electronics where low power consumption and high performance are necessary.
Q & A
- What is the primary function of the 74LVC138AD-Q100J?
The primary function of the 74LVC138AD-Q100J is to act as a 3-to-8 line decoder/demultiplexer.
- What is the operating voltage range of the 74LVC138AD-Q100J?
The operating voltage range is from 1.2V to 3.6V.
- What is the operating temperature range of the device?
The device operates in a temperature range from -40°C to 125°C.
- What type of package does the 74LVC138AD-Q100J come in?
The device comes in a 16-SOIC package.
- Is the 74LVC138AD-Q100J RoHS compliant?
Yes, the device is RoHS compliant.
- What are some typical applications of the 74LVC138AD-Q100J?
Typical applications include digital logic circuits, automotive systems, industrial control systems, and consumer electronics.
- What is the current output capability of the 74LVC138AD-Q100J?
The device can output up to 24mA for both high and low states.
- Is the 74LVC138AD-Q100J AEC-Q100 qualified?
Yes, the device is AEC-Q100 qualified, making it suitable for automotive applications.
- What is the mounting type of the 74LVC138AD-Q100J?
The device is a surface mount component.
- Where can I find detailed specifications and datasheets for the 74LVC138AD-Q100J?
Detailed specifications and datasheets can be found on the official Nexperia website, as well as on distributor websites like Digi-Key, Mouser, and others.
