Overview
The 74AUP2G14GW,125 is a low-power dual Schmitt trigger inverter produced by Nexperia USA Inc. This integrated circuit is designed to provide very low static and dynamic power consumption, making it suitable for a wide range of applications where power efficiency is crucial. The device features Schmitt-trigger inputs, which help in noise immunity and stable output signals.
Key Specifications
| Parameter | Value |
|---|---|
| Device Type | Dual Inverter with Schmitt-trigger inputs |
| Package Type | 6-TSSOP |
| Number of Channels | 2 |
| Supply Voltage Range | 0.8 V to 3.6 V |
| Static Power Consumption | Very low |
| Dynamic Power Consumption | Very low |
| Operating Temperature Range | -40°C to 125°C |
Key Features
- Low static and dynamic power consumption
- Schmitt-trigger inputs for improved noise immunity
- Wide supply voltage range (0.8 V to 3.6 V)
- Compact 6-TSSOP package
- Operating temperature range from -40°C to 125°C
Applications
The 74AUP2G14GW,125 is suitable for various applications where low power consumption and noise immunity are essential. These include:
- Mobile devices and handheld equipment
- Automotive electronics
- Industrial control systems
- Consumer electronics
- IoT devices
Q & A
- What is the primary function of the 74AUP2G14GW,125?
The primary function is to act as a dual inverter with Schmitt-trigger inputs.
- What is the package type of the 74AUP2G14GW,125?
The package type is 6-TSSOP.
- What is the supply voltage range for this device?
The supply voltage range is from 0.8 V to 3.6 V.
- Why are Schmitt-trigger inputs important?
Schmitt-trigger inputs provide improved noise immunity and stable output signals.
- What are the typical applications for this device?
Typical applications include mobile devices, automotive electronics, industrial control systems, consumer electronics, and IoT devices.
- What is the operating temperature range of the 74AUP2G14GW,125?
The operating temperature range is from -40°C to 125°C.
- How does this device contribute to power efficiency?
The device contributes to power efficiency through its very low static and dynamic power consumption.
- Who is the manufacturer of the 74AUP2G14GW,125?
The manufacturer is Nexperia USA Inc.
- Where can I find detailed specifications and datasheets for this device?
Detailed specifications and datasheets can be found on the Nexperia official website or through distributors like Digi-Key and Mouser.
- What are the benefits of using a 6-TSSOP package?
The 6-TSSOP package is compact, which helps in saving PCB space and is suitable for designs where space is limited.
