2N2222AUB/TR
  • Share:

Microchip Technology 2N2222AUB/TR

Manufacturer No:
2N2222AUB/TR
Manufacturer:
Microchip Technology
Package:
Tape & Reel (TR)
Description:
TRANS NPN 50V 0.8A 3SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The 2N2222AUB/TR is a surface-mount NPN general-purpose transistor produced by Microchip Technology. This transistor is part of the 2N2222 series and is designed for a variety of small-signal and switching applications. It is known for its reliability and performance in various electronic circuits.

Key Specifications

ParameterValue
Transistor TypeNPN
Package / Case3-SMD, No Lead
Mounting TypeSurface Mount
Power - Max500 mW
Operating Temperature-65°C ~ 200°C (TJ)
Vce Saturation (Max) @ Ib, Ic1V @ 50mA, 500mA
Current - Collector (Ic) (Max)800 mA
Current - Collector Cutoff (Max)50 nA
DC Current Gain (hFE) (Min) @ Ic, Vce100 @ 150mA, 10V
Voltage - Collector Emitter Breakdown (Max)50 V

Key Features

  • High Current Gain: The 2N2222AUB/TR has a minimum DC current gain (hFE) of 100 at 150mA and 10V, making it suitable for amplification and switching applications.
  • Low Saturation Voltage: With a Vce saturation of 1V at 50mA and 500mA, it ensures efficient operation in various circuits.
  • Wide Operating Temperature Range: The transistor can operate over a temperature range of -65°C to 200°C, enhancing its reliability in diverse environments.
  • Surface Mount Package: The 3-SMD package facilitates easy integration into surface-mount technology (SMT) boards.

Applications

The 2N2222AUB/TR is versatile and can be used in a variety of applications, including:

  • Small-Signal Amplification: Suitable for audio and general-purpose amplification circuits.
  • Switching Circuits: Ideal for use in switching applications due to its high current gain and low saturation voltage.
  • Automotive and Industrial Control: Its robustness and wide operating temperature range make it suitable for use in automotive and industrial control systems.
  • Consumer Electronics: Used in various consumer electronic devices requiring reliable and efficient transistor performance.

Q & A

  1. What is the maximum collector current of the 2N2222AUB/TR transistor?
    The maximum collector current is 800 mA.
  2. What is the operating temperature range of the 2N2222AUB/TR?
    The operating temperature range is -65°C to 200°C (TJ).
  3. What is the package type of the 2N2222AUB/TR transistor?
    The package type is 3-SMD, No Lead.
  4. What is the minimum DC current gain (hFE) of the 2N2222AUB/TR?
    The minimum DC current gain (hFE) is 100 at 150mA and 10V.
  5. What is the maximum power dissipation of the 2N2222AUB/TR?
    The maximum power dissipation is 500 mW.
  6. Is the 2N2222AUB/TR RoHS compliant?
    Yes, the 2N2222AUB/TR is RoHS compliant.
  7. What is the collector-emitter breakdown voltage of the 2N2222AUB/TR?
    The collector-emitter breakdown voltage is 50 V.
  8. What are some common applications of the 2N2222AUB/TR transistor?
    Common applications include small-signal amplification, switching circuits, automotive and industrial control, and consumer electronics.
  9. How is the 2N2222AUB/TR typically packaged for distribution?
    The 2N2222AUB/TR is typically packaged in Tape & Reel (TR) for distribution.
  10. What are the certifications associated with the 2N2222AUB/TR?
    The transistor is qualified per MIL-PRF-19500/255 and is ISO9001 and AS9120 certified.

Product Attributes

Transistor Type:NPN
Current - Collector (Ic) (Max):800 mA
Voltage - Collector Emitter Breakdown (Max):50 V
Vce Saturation (Max) @ Ib, Ic:1V @ 50mA, 500mA
Current - Collector Cutoff (Max):50nA
DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 10V
Power - Max:500 mW
Frequency - Transition:-
Operating Temperature:-65°C ~ 200°C (TJ)
Mounting Type:Surface Mount
Package / Case:3-SMD, No Lead
Supplier Device Package:3-SMD
