Overview
The ADBF525WBBCZ502 is a high-performance Blackfin embedded processor manufactured by Analog Devices Inc. This processor is part of the ADSP-BF52x series and is designed for a wide range of applications, including automotive, industrial control systems, medical devices, and consumer electronics. The ADBF525WBBCZ502 operates at a clock rate of 533 MHz and features a fixed-point processing architecture, making it suitable for demanding signal processing tasks.
Key Specifications
| Specification | Details |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Part Number | ADBF525WBBCZ502 |
| Category | Integrated Circuits - ICs, Embedded - DSP |
| Package | 208-FBGA, CSPBGA |
| Clock Rate | 533 MHz |
| On-Chip RAM | 132 kB |
| Non-Volatile Memory (ROM) | 32 kB |
| Interfaces | DMA, I2C, PPI, SPI, SPORT, UART, USB |
| Voltage - Core | 1.10 V |
| Voltage - I/O | 1.8 V, 2.5 V, 3.3 V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| RoHS Status | ROHS Compliant |
Key Features
- Fixed-point processing architecture
- Up to 533 MHz clock rate
- 132 kB of on-chip RAM and 32 kB of non-volatile memory (ROM)
- Multiple interfaces: DMA, I2C, PPI, SPI, SPORT, UART, USB
- Programmable on-chip voltage regulator (for ADSP-BF523/ADSP-BF525/ADSP-BF527 processors only)
- Advanced debug, trace, and performance monitoring
- Eight 32-bit timers/counters with PWM support and real-time clock (RTC) and watchdog timer
- 48 general-purpose I/Os (GPIOs) with programmable hysteresis
- NAND flash controller (NFC) and debug/JTAG interface
Applications
- Automotive applications: infotainment systems, driver assistance, and autonomous driving
- Industrial control systems
- Medical devices: diagnostic equipment and patient monitoring systems
- Consumer electronics: smart home appliances and IoT devices
- Other industries: aerospace, defense, and more
Q & A
- What is the clock rate of the ADBF525WBBCZ502 processor?
The ADBF525WBBCZ502 operates at a clock rate of 533 MHz. - What type of processing architecture does the ADBF525WBBCZ502 use?
The ADBF525WBBCZ502 uses a fixed-point processing architecture. - How much on-chip RAM and ROM does the ADBF525WBBCZ502 have?
The ADBF525WBBCZ502 has 132 kB of on-chip RAM and 32 kB of non-volatile memory (ROM). - What interfaces are supported by the ADBF525WBBCZ502?
The ADBF525WBBCZ502 supports DMA, I2C, PPI, SPI, SPORT, UART, and USB interfaces. - What is the operating temperature range of the ADBF525WBBCZ502?
The operating temperature range is -40°C ~ 85°C (TA). - Is the ADBF525WBBCZ502 ROHS compliant?
Yes, the ADBF525WBBCZ502 is ROHS compliant. - What are some of the key applications of the ADBF525WBBCZ502?
The ADBF525WBBCZ502 is used in automotive, industrial control systems, medical devices, consumer electronics, and other industries. - Does the ADBF525WBBCZ502 have a programmable on-chip voltage regulator?
Yes, the ADBF525WBBCZ502 has a programmable on-chip voltage regulator (for ADSP-BF523/ADSP-BF525/ADSP-BF527 processors only). - What kind of timers and counters does the ADBF525WBBCZ502 support?
The ADBF525WBBCZ502 supports eight 32-bit timers/counters with PWM support and a real-time clock (RTC) and watchdog timer. - How many general-purpose I/Os (GPIOs) does the ADBF525WBBCZ502 have?
The ADBF525WBBCZ502 has 48 general-purpose I/Os (GPIOs) with programmable hysteresis.
