Overview
The AD6600ASTZ is a high-performance, 11-bit analog-to-digital converter (ADC) produced by Analog Devices Inc. This dual-channel, pipelined ADC is designed for applications requiring high-speed and high-accuracy data conversion. It features a gain-ranging capability and includes an integrated RSSI (Received Signal Strength Indicator) function, making it suitable for a variety of signal processing tasks.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 11 bits |
| Number of Channels | 2 |
| Conversion Type | Pipelined |
| Package Type | 44-LQFP (10x10 mm) |
| Supply Voltage | 1.8V to 3.6V |
| Sampling Rate | Up to 250 MSPS per channel |
| Gain Ranging | Yes |
| Integrated RSSI | Yes |
Key Features
- Dual-channel, 11-bit pipelined ADC for high-speed data conversion.
- Gain-ranging capability for flexible signal handling.
- Integrated RSSI function for signal strength measurement.
- Low power consumption, suitable for battery-powered devices.
- High accuracy and linearity, ensuring reliable data conversion.
Applications
The AD6600ASTZ is versatile and can be used in various applications, including:
- Wireless communication systems, such as base stations and handsets.
- Medical imaging and diagnostic equipment.
- Aerospace and defense systems requiring high-speed data acquisition.
- Industrial automation and control systems.
- High-speed data acquisition systems in scientific research.
Q & A
- What is the resolution of the AD6600ASTZ ADC?
The AD6600ASTZ has a resolution of 11 bits. - How many channels does the AD6600ASTZ support?
The AD6600ASTZ supports two channels. - What is the maximum sampling rate of the AD6600ASTZ?
The maximum sampling rate is up to 250 MSPS per channel. - Does the AD6600ASTZ have an integrated RSSI function?
Yes, the AD6600ASTZ includes an integrated RSSI function. - What is the package type of the AD6600ASTZ?
The AD6600ASTZ comes in a 44-LQFP (10x10 mm) package. - What is the supply voltage range for the AD6600ASTZ?
The supply voltage range is from 1.8V to 3.6V. - Is the AD6600ASTZ suitable for high-speed data acquisition?
Yes, it is designed for high-speed data acquisition applications. - Does the AD6600ASTZ support gain-ranging?
Yes, the AD6600ASTZ supports gain-ranging. - What are some common applications of the AD6600ASTZ?
Common applications include wireless communication systems, medical imaging, aerospace and defense systems, industrial automation, and high-speed data acquisition in scientific research. - Where can I find detailed specifications and datasheets for the AD6600ASTZ?
Detailed specifications and datasheets can be found on the official Analog Devices website, as well as through distributors like Mouser, Digi-Key, and Heisener.
