Overview
The TMS320VC5410AGGU1 is a fixed-point digital signal processor (DSP) developed by Texas Instruments. It is based on an advanced modified Harvard architecture, which includes one program memory bus and three data memory buses. This architecture allows for simultaneous access to program instructions and data, providing a high degree of parallelism. The processor is designed for high-performance signal processing applications and features a specialized instruction set that supports powerful arithmetic, logic, and bit-manipulation operations.
Key Specifications
Specification | Details |
---|---|
Package Type | 144-Ball GGU MicroStar BGA™, 144-Pin PGE Low-Profile Quad Flatpack (LQFP) |
Core Supply Voltage | 1.6 V (160 MIPS), 1.5 V (120 MIPS) |
Memory | On-Chip RAM, On-Chip ROM with Bootloader, Extended Program Memory, Data Memory, Program Memory |
Arithmetic Logic Unit (ALU) | 40-Bit ALU with 40-Bit Barrel Shifter and Two Independent 40-Bit Accumulators |
Multiply/Accumulate (MAC) | Single-Cycle Multiply/Accumulate Operation |
Peripherals | Software-Programmable Wait-State Generator, Programmable Bank-Switching, Bus Holders, Enhanced 8-/16-Bit Host-Port Interface (HPI8/16), Multichannel Buffered Serial Ports (McBSPs), Hardware Timer, DMA Controller |
Clock Generator | Programmable Phase-Locked Loop (PLL) Clock Generator with Internal Oscillator or External Clock Source |
Power Consumption Control | IDLE1, IDLE2, and IDLE3 Instructions with Power-Down Modes |
Key Features
- Advanced Multibus Architecture with three separate 16-bit data memory buses and one program memory bus
- Conditional Store Instructions and Fast Return From Interrupt
- 40-Bit Arithmetic Logic Unit (ALU) including a 40-Bit Barrel Shifter and two independent 40-Bit Accumulators
- Single-Cycle Multiply/Accumulate (MAC) Operation
- On-Chip Peripherals: Software-Programmable Wait-State Generator, Programmable Bank-Switching, Bus Holders, Enhanced 8-/16-Bit Host-Port Interface (HPI8/16), Multichannel Buffered Serial Ports (McBSPs), Hardware Timer, DMA Controller
- Programmable Phase-Locked Loop (PLL) Clock Generator with Internal Oscillator or External Clock Source
- IDLE1, IDLE2, and IDLE3 Instructions with Power-Down Modes
- IEEE Standard 1149.1-1990 Standard-Test-Access Port and Boundary Scan Architecture
Applications
The TMS320VC5410AGGU1 is commonly used in various signal processing applications, including but not limited to:
- Audio and Video Processing
- Telecommunications
- Medical Imaging and Diagnostics
- Industrial Control Systems
- Aerospace and Defense Systems
Q & A
- What is the TMS320VC5410AGGU1?
The TMS320VC5410AGGU1 is a fixed-point digital signal processor (DSP) developed by Texas Instruments.
- What architecture does the TMS320VC5410AGGU1 use?
It uses an advanced modified Harvard architecture with one program memory bus and three data memory buses.
- What are the key features of the TMS320VC5410AGGU1's ALU?
The ALU includes a 40-Bit Barrel Shifter and two independent 40-Bit Accumulators.
- Does the TMS320VC5410AGGU1 support power management?
Yes, it supports power management through IDLE1, IDLE2, and IDLE3 instructions with power-down modes.
- What types of peripherals are included in the TMS320VC5410AGGU1?
It includes peripherals such as Software-Programmable Wait-State Generator, Programmable Bank-Switching, Bus Holders, Enhanced 8-/16-Bit Host-Port Interface (HPI8/16), Multichannel Buffered Serial Ports (McBSPs), Hardware Timer, and DMA Controller.
- What is the clock generator capability of the TMS320VC5410AGGU1?
It has a Programmable Phase-Locked Loop (PLL) Clock Generator with Internal Oscillator or External Clock Source.
- What are the typical applications of the TMS320VC5410AGGU1?
It is used in audio and video processing, telecommunications, medical imaging and diagnostics, industrial control systems, and aerospace and defense systems.
- What are the package options for the TMS320VC5410AGGU1?
It is available in 144-Ball GGU MicroStar BGA™ and 144-Pin PGE Low-Profile Quad Flatpack (LQFP) packages.
- What is the core supply voltage range for the TMS320VC5410AGGU1?
The core supply voltage range is 1.6 V (160 MIPS) and 1.5 V (120 MIPS).
- Does the TMS320VC5410AGGU1 support boundary scan architecture?
Yes, it supports IEEE Standard 1149.1-1990 Standard-Test-Access Port and Boundary Scan Architecture.
