Overview
The TM4C123GH6ZRBTR is a high-performance microcontroller unit (MCU) from Texas Instruments, designed for embedded applications requiring robust processing capabilities and versatile connectivity options. This MCU is part of the Tiva™ C Series, which is renowned for its ARM Cortex-M4F core, offering a balance of performance and energy efficiency. The TM4C123GH6ZRBTR is targeted at developers and engineers working on industrial automation, consumer electronics, and automotive systems. Its unique selling points include advanced peripherals, low power consumption, and extensive development support, making it a competitive choice in the embedded systems market.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Core | ARM Cortex-M4F | - | With FPU |
| Clock Speed | 80 | MHz | - |
| Flash Memory | 256 | KB | - |
| SRAM | 32 | KB | - |
| Operating Voltage | 1.8 to 3.6 | V | - |
| GPIO Pins | 43 | - | - |
| Communication Interfaces | UART, SPI, I2C, CAN, USB | - | - |
| Package | LQFP | - | 64-pin |
| Operating Temperature | -40 to 85 | °C | - |
| Datasheet | TM4C123GH6ZRBTR Datasheet | - | Official source |
Key Features
- ARM Cortex-M4F Core: Delivers high performance with floating-point unit (FPU) support for complex calculations.
- Integrated Peripherals: Includes UART, SPI, I2C, CAN, and USB interfaces for versatile connectivity.
- Low Power Modes: Optimized for energy-efficient operation in battery-powered applications.
- Comprehensive Development Tools: Supported by Texas Instruments' TivaWare™ software suite and ecosystem.
- Robust Security Features: Provides hardware-based security for sensitive applications.
Applications
The TM4C123GH6ZRBTR is widely used in various industries due to its versatility and performance. Key application areas include:
- Industrial Automation: Ideal for motor control, PLCs, and monitoring systems.
- Consumer Electronics: Suitable for smart home devices, wearables, and IoT applications.
- Automotive Systems: Used in infotainment, body control, and diagnostic systems.
- Medical Devices: Supports portable medical equipment and monitoring devices.
Q & A
1. What is the core architecture of the TM4C123GH6ZRBTR?
The TM4C123GH6ZRBTR is based on the ARM Cortex-M4F core with a floating-point unit.
2. What is the maximum clock speed of this MCU?
The maximum clock speed is 80 MHz.
3. How much flash memory does it have?
It features 256 KB of flash memory.
4. What is the operating voltage range?
The operating voltage ranges from 1.8 V to 3.6 V.
5. What communication interfaces are supported?
It supports UART, SPI, I2C, CAN, and USB interfaces.
6. What is the package type of this MCU?
It comes in a 64-pin LQFP package.
7. Is this MCU suitable for low-power applications?
Yes, it features multiple low-power modes for energy-efficient operation.
8. What development tools are available for this MCU?
Texas Instruments provides the TivaWare™ software suite and ecosystem for development.
9. Can it be used in automotive applications?
Yes, it is suitable for automotive systems like infotainment and body control.
10. Where can I find the official datasheet?
The official datasheet is available on the Texas Instruments website.
