Overview
The INA350ABSIDSGR is a high-precision, low-power current sense amplifier manufactured by Texas Instruments. This model is designed for applications requiring accurate current measurement and monitoring. It is part of the INA350 series, which is widely recognized for its reliability and performance in various industrial and consumer electronics applications. The INA350ABSIDSGR is particularly suited for battery-powered devices, portable electronics, and IoT applications due to its low power consumption and compact form factor. Its unique selling points include its high accuracy, wide input voltage range, and integrated features that simplify design and reduce external component count.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Supply Voltage | 2.7 to 5.5 | V | |
| Quiescent Current | 60 | µA | |
| Gain | 50 | V/V | |
| Bandwidth | 350 | kHz | |
| Input Offset Voltage | ±150 | µV | |
| Operating Temperature Range | -40 to 125 | °C | |
| Package | DSBGA | 8-pin |
Key Features
- High accuracy with low offset voltage
- Low power consumption, ideal for battery-powered applications
- Wide supply voltage range for versatile use
- Integrated gain setting resistors for simplified design
- Compact DSBGA package for space-constrained applications
Applications
The INA350ABSIDSGR is ideal for a variety of applications including portable electronics, battery management systems, and IoT devices. Its high precision and low power consumption make it suitable for use in power-sensitive applications where accurate current monitoring is crucial. Additionally, its compact form factor and integrated features make it a preferred choice for space-constrained designs.
Q & A
What is the supply voltage range of the INA350ABSIDSGR?
The supply voltage range is 2.7V to 5.5V.
What is the quiescent current of the INA350ABSIDSGR?
The quiescent current is 60µA.
What is the gain of the INA350ABSIDSGR?
The gain is 50V/V.
What is the bandwidth of the INA350ABSIDSGR?
The bandwidth is 350kHz.
What is the input offset voltage of the INA350ABSIDSGR?
The input offset voltage is ±150µV.
What is the operating temperature range of the INA350ABSIDSGR?
The operating temperature range is -40°C to 125°C.
What package does the INA350ABSIDSGR come in?
It comes in an 8-pin DSBGA package.
Is the INA350ABSIDSGR suitable for battery-powered applications?
Yes, its low power consumption makes it ideal for battery-powered applications.
Can the INA350ABSIDSGR be used in IoT devices?
Yes, its compact form factor and low power consumption make it suitable for IoT devices.
Does the INA350ABSIDSGR have integrated gain setting resistors?
Yes, it has integrated gain setting resistors for simplified design.
