Overview
The F28386SZWTS is a high-performance microcontroller from Texas Instruments, designed for advanced real-time control applications. This model is part of the C2000™ 32-bit microcontroller series, known for its precision and efficiency in industrial automation, automotive, and renewable energy systems. The F28386SZWTS is particularly targeted at engineers and developers working on complex control systems that require high-speed processing, robust connectivity, and enhanced safety features. Its unique selling points include integrated floating-point units, high-resolution PWM outputs, and advanced analog peripherals, making it a competitive choice for demanding applications.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Core Architecture | C28x + CLA | - | Dual-core design |
| CPU Speed | 200 | MHz | Max operating frequency |
| Flash Memory | 1 | MB | On-chip program memory |
| RAM | 204 | KB | On-chip data memory |
| Analog-to-Digital Converter (ADC) | 16-bit | - | High-resolution ADC |
| PWM Channels | 24 | - | High-resolution PWM |
| Operating Temperature | -40 to 105 | °C | Industrial-grade |
| Package | BGA | - | 337-pin |
| Supply Voltage | 1.14 to 1.32 | V | Core voltage |
| Connectivity | CAN, SPI, I2C, UART | - | Multiple communication interfaces |
Key Features
- Dual-Core Architecture: Combines C28x CPU and CLA for efficient parallel processing.
- High-Resolution PWM: Enables precise motor control and power conversion.
- Integrated Analog Peripherals: Includes 16-bit ADC and comparators for accurate signal processing.
- Enhanced Safety Features: Supports functional safety standards like ISO 26262 for automotive applications.
- Robust Connectivity: Offers multiple communication interfaces for seamless system integration.
Applications
The F28386SZWTS is widely used in various industries due to its advanced capabilities. In industrial automation, it powers motor control systems, robotics, and PLCs. In the automotive sector, it is employed in electric vehicle powertrains, advanced driver-assistance systems (ADAS), and battery management systems. Additionally, it finds applications in renewable energy systems, such as solar inverters and wind turbine controllers, where its high-performance processing and precision are critical. Its versatility and reliability make it a preferred choice for engineers designing next-generation control systems.
Q & A
1. What is the operating temperature range of the F28386SZWTS?
The F28386SZWTS operates within a temperature range of -40°C to 105°C, making it suitable for industrial environments.
2. Does the F28386SZWTS support functional safety standards?
Yes, it supports functional safety standards like ISO 26262, making it ideal for automotive applications.
3. What is the maximum CPU speed of the F28386SZWTS?
The maximum CPU speed is 200 MHz, ensuring high-speed processing for real-time control tasks.
4. How much flash memory does the F28386SZWTS have?
It has 1 MB of on-chip flash memory for program storage.
5. What communication interfaces are available on the F28386SZWTS?
It supports CAN, SPI, I2C, and UART interfaces for robust connectivity.
6. What is the resolution of the ADC in the F28386SZWTS?
The ADC has a resolution of 16 bits, providing high accuracy for analog signal processing.
7. How many PWM channels does the F28386SZWTS offer?
It provides 24 high-resolution PWM channels for precise control applications.
8. What is the core voltage of the F28386SZWTS?
The core voltage ranges from 1.14 V to 1.32 V.
9. Is the F28386SZWTS suitable for renewable energy systems?
Yes, its high-performance processing and precision make it ideal for applications like solar inverters and wind turbine controllers.
10. What package type does the F28386SZWTS use?
It comes in a 337-pin BGA package.
