Overview
The DS25CP152TSQ/NOPB is a high-performance 3.125 Gbps 2x2 LVDS (Low Voltage Differential Signaling) crosspoint switch manufactured by Texas Instruments. This component is optimized for high-speed signal routing and switching, particularly over lossy FR-4 printed circuit board backplanes and balanced cables. It is designed to support high-speed data transmission, making it suitable for various high-bandwidth applications.
Key Specifications
| Parameter | Value |
|---|---|
| Data Rate | Up to 3.125 Gbps |
| Number of Channels | 2x2 |
| Signal Type | LVDS |
| Operating Temperature | -40°C to 85°C |
| Package Type | WQFN-16 |
| Supply Voltage | 3.3V ± 10% |
| Supports | USB 3.1 up to 5Gbps, DisplayPort 1.4 up to 8.1Gbps |
Key Features
- High-speed signal routing and switching up to 3.125 Gbps
- Optimized for use over lossy FR-4 printed circuit board backplanes and balanced cables
- Supports USB 3.1 data rates up to 5Gbps and DisplayPort 1.4 up to 8.1Gbps for downstream facing ports
- Low power consumption
- Compact WQFN-16 package
Applications
- High-speed data transmission systems
- DisplayPort and USB 3.1 interfaces
- Server and storage systems
- High-performance computing
- Telecommunication equipment
Q & A
- What is the maximum data rate supported by the DS25CP152TSQ/NOPB? The DS25CP152TSQ/NOPB supports data rates up to 3.125 Gbps.
- What type of signal does the DS25CP152TSQ/NOPB use? The DS25CP152TSQ/NOPB uses LVDS (Low Voltage Differential Signaling).
- What are the operating temperature ranges for the DS25CP152TSQ/NOPB? The operating temperature range is -40°C to 85°C.
- What package type is the DS25CP152TSQ/NOPB available in? The DS25CP152TSQ/NOPB is available in a WQFN-16 package.
- Does the DS25CP152TSQ/NOPB support USB 3.1 and DisplayPort? Yes, it supports USB 3.1 up to 5Gbps and DisplayPort 1.4 up to 8.1Gbps.
- What is the typical supply voltage for the DS25CP152TSQ/NOPB? The typical supply voltage is 3.3V ± 10%.
- What are some common applications for the DS25CP152TSQ/NOPB? Common applications include high-speed data transmission systems, DisplayPort and USB 3.1 interfaces, server and storage systems, high-performance computing, and telecommunication equipment.
- Is the DS25CP152TSQ/NOPB optimized for use over lossy FR-4 printed circuit board backplanes? Yes, it is optimized for use over lossy FR-4 printed circuit board backplanes and balanced cables.
- Who manufactures the DS25CP152TSQ/NOPB? The DS25CP152TSQ/NOPB is manufactured by Texas Instruments.
- What is the significance of the 'NOPB' suffix in the part number? The 'NOPB' suffix indicates that the component is free from lead (Pb) and is RoHS compliant.
