Overview
The ADS8342IPFBT is a high-performance 16-bit analog-to-digital converter (ADC) manufactured by Texas Instruments. Designed for precision data acquisition, this ADC is part of the ADS8342 series and is housed in a TQFP-48 package. It features a parallel interface and supports a sampling rate of up to 250 kS/s. With its single-ended input structure and SAR architecture, the ADS8342IPFBT is ideal for applications requiring high accuracy and reliability. Its robust design and wide operating temperature range make it suitable for industrial, automotive, and consumer electronics applications.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Resolution | 16 | bit | - |
| Channels | 4 | Channel | - |
| Interface | Parallel | - | - |
| Sampling Rate | 250 | kS/s | - |
| Input Type | Single-Ended | - | - |
| Architecture | SAR | - | - |
| Analog Supply Voltage | 4.75 to 5.25 | V | - |
| Digital Supply Voltage | 2.7 to 5.5 | V | - |
| SNR | 86 | dB | - |
| Operating Temperature | -40 to +85 | °C | - |
| Power Dissipation | 250 | mW | Max |
| Package | TQFP-48 | - | - |
Key Features
- High-resolution 16-bit ADC for precise data acquisition.
- Supports up to 4 single-ended input channels.
- Parallel interface for fast data transfer.
- Wide operating temperature range (-40°C to +85°C) for robust performance in harsh environments.
- Low power consumption, making it suitable for portable and battery-powered applications.
Applications
The ADS8342IPFBT is widely used in applications requiring high-accuracy analog-to-digital conversion. Its key application areas include industrial automation, where it is used for process control and monitoring; automotive systems, such as engine management and sensor interfaces; and consumer electronics, including medical devices and audio equipment. Its high resolution and reliability make it a preferred choice for precision measurement and data acquisition systems.
