Overview
The ADC12662CIV is a 12-bit analog-to-digital converter (ADC) produced by National Semiconductor, now part of Texas Instruments. This component is designed to provide high-speed and high-resolution conversion, making it suitable for a variety of applications that require precise analog-to-digital conversion.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 12 bits |
| Conversion Rate | Up to 200 kSPS |
| Input Range | 0 to 5V (or other ranges depending on configuration) |
| Power Supply | Single 5V supply |
| Power Consumption | Typically 15 mW at 200 kSPS |
| Package Type | V44A (44-pin TSSOP) |
| Operating Temperature | -40°C to 85°C |
| Interface | SPI-compatible serial interface |
Key Features
- High-speed conversion rate of up to 200 kSPS
- Low power consumption, typically 15 mW at 200 kSPS
- SPI-compatible serial interface for easy communication with microcontrollers
- High resolution of 12 bits for precise analog-to-digital conversion
- Single 5V power supply for simplicity in system design
- Operating temperature range from -40°C to 85°C, making it suitable for various environmental conditions
Applications
The ADC12662CIV is versatile and can be used in a wide range of applications, including:
- Industrial control systems
- Medical devices requiring high precision
- Aerospace and defense systems
- Automotive systems
- Data acquisition systems
Q & A
- What is the resolution of the ADC12662CIV?
The ADC12662CIV has a resolution of 12 bits. - What is the maximum conversion rate of the ADC12662CIV?
The maximum conversion rate is up to 200 kSPS. - What is the typical power consumption of the ADC12662CIV at 200 kSPS?
The typical power consumption is 15 mW at 200 kSPS. - What type of package does the ADC12662CIV come in?
The ADC12662CIV comes in a 44-pin TSSOP package (V44A). - What is the operating temperature range of the ADC12662CIV?
The operating temperature range is from -40°C to 85°C. - Does the ADC12662CIV support SPI interface?
Yes, it supports an SPI-compatible serial interface. - What is the input voltage range for the ADC12662CIV?
The input voltage range is typically 0 to 5V, but can be configured for other ranges. - Is the ADC12662CIV RoHS compliant?
No, the ADC12662CIV is not RoHS compliant. - What are some common applications of the ADC12662CIV?
Common applications include industrial control systems, medical devices, aerospace and defense systems, automotive systems, and data acquisition systems. - Who is the manufacturer of the ADC12662CIV?
The manufacturer is National Semiconductor, now part of Texas Instruments.
