Overview
The MK20DX256VLH7, produced by NXP USA Inc., is a member of the Kinetis K20 family of microcontrollers. These microcontrollers are based on the Arm Cortex-M4 core and are designed to offer a scalable entry point into the mid-performance Kinetis portfolio. They are known for their high-performance capabilities, mixed-signal integration, and full-speed USB functionality, making them suitable for a wide range of applications that require advanced processing and connectivity.
Key Specifications
| Parameter | Value |
|---|---|
| Core | Arm Cortex-M4 |
| Operating Frequency | 72 MHz |
| Flash Memory | 256 KB |
| SRAM | 64 KB |
| Package Type | 64-LQFP (10x10 mm) |
| USB Interface | Full-Speed USB |
| Temperature Range | -40°C to 105°C |
Key Features
- High-Performance Processing: The MK20DX256VLH7 is powered by the Arm Cortex-M4 core, providing high-performance processing capabilities.
- Mixed-Signal Integration: Includes a variety of analog and digital peripherals, enhancing the microcontroller's versatility.
- Full-Speed USB: Supports full-speed USB 2.0, enabling fast data transfer and connectivity.
- Low Power Consumption: Designed to operate efficiently, making it suitable for battery-powered devices.
- Robust Security Features: Includes various security features to protect data and ensure secure operation.
Applications
The MK20DX256VLH7 microcontroller is versatile and can be used in a variety of applications, including:
- Industrial Automation: For control and monitoring systems in industrial environments.
- Consumer Electronics: In devices such as smart home appliances, gaming consoles, and other consumer electronics.
- Medical Devices: For medical equipment that requires precise control and high-performance processing.
- Automotive Systems: In automotive applications that need robust and reliable microcontrollers.
- IoT Devices: For Internet of Things (IoT) devices that require advanced processing and connectivity.
Q & A
- What is the core architecture of the MK20DX256VLH7 microcontroller?
The MK20DX256VLH7 is based on the Arm Cortex-M4 core. - What is the operating frequency of the MK20DX256VLH7?
The operating frequency is 72 MHz. - How much flash memory does the MK20DX256VLH7 have?
The microcontroller has 256 KB of flash memory. - What type of USB interface does the MK20DX256VLH7 support?
The MK20DX256VLH7 supports full-speed USB 2.0. - What is the package type of the MK20DX256VLH7?
The package type is 64-LQFP (10x10 mm). - What is the temperature range for the MK20DX256VLH7?
The temperature range is -40°C to 105°C. - What are some key features of the MK20DX256VLH7?
Key features include high-performance processing, mixed-signal integration, full-speed USB, and low power consumption. - In what types of applications can the MK20DX256VLH7 be used?
The microcontroller can be used in industrial automation, consumer electronics, medical devices, automotive systems, and IoT devices. - Does the MK20DX256VLH7 have any security features?
Yes, it includes various security features to protect data and ensure secure operation. - Where can I find detailed specifications for the MK20DX256VLH7?
Detailed specifications can be found on NXP's official website and other component distributor sites like Digi-Key and Mouser.
