Overview
The MK10DX128VFM5 is a 32-bit microcontroller from NXP USA Inc., part of the Kinetis K10 family. This microcontroller is designed for high feature integration in a small form factor, making it ideal for space- and cost-constrained applications. It features a 50 MHz ARM Cortex-M4 core with DSP instructions, providing high performance and low power consumption. The device is well-suited for a variety of applications requiring advanced processing capabilities and efficient power management.
Key Specifications
| Parameter | Value |
|---|---|
| Core Processor | ARM® Cortex®-M4 |
| Operating Frequency | Up to 50 MHz |
| Supply Voltage | 1.71 V to 3.6 V |
| Program Memory | 128 KB Flash |
| RAM Size | 16 KB |
| EEPROM Size | 2 KB |
| Package Type | 32-QFN (5 mm x 5 mm) |
| Operating Temperature | -40°C to 105°C |
| Number of I/O Pins | 44 |
| Communication Interfaces | I²C, IrDA, SPI, UART/USART |
| Analog to Digital Converter (ADC) | 19x16-bit |
Key Features
- High-performance ARM Cortex-M4 core with DSP instructions, delivering 1.25 Dhrystone MIPS per MHz.
- Low power consumption with multiple low-power modes.
- Integrated DMA controller, I²S, LVD, POR, PWM, and WDT.
- Robust serial communication interfaces including I²C, IrDA, SPI, and UART/USART.
- FlexMemory technology with up to 32 KB FlexNVM and 2 KB FlexRAM.
- Internal and external clock options including a 3 to 32 MHz crystal oscillator and a 32 kHz crystal oscillator.
Applications
The MK10DX128VFM5 is versatile and can be used in a wide range of applications, including:
- Industrial control systems.
- Consumer electronics.
- Medical devices.
- Automotive systems.
- Internet of Things (IoT) devices.
- Smart home appliances.
Q & A
- What is the core processor of the MK10DX128VFM5?
The core processor is the ARM® Cortex®-M4. - What is the maximum operating frequency of the MK10DX128VFM5?
The maximum operating frequency is up to 50 MHz. - What is the supply voltage range for the MK10DX128VFM5?
The supply voltage range is from 1.71 V to 3.6 V. - How much program memory does the MK10DX128VFM5 have?
The MK10DX128VFM5 has 128 KB of Flash program memory. - What is the RAM size of the MK10DX128VFM5?
The RAM size is 16 KB. - What are the communication interfaces available on the MK10DX128VFM5?
The communication interfaces include I²C, IrDA, SPI, and UART/USART. - What is the operating temperature range of the MK10DX128VFM5?
The operating temperature range is from -40°C to 105°C. - How many programmable I/O pins does the MK10DX128VFM5 have?
The device has 44 programmable I/O pins. - Does the MK10DX128VFM5 support low-power modes?
Yes, it supports multiple low-power modes for power optimization. - What is the package type of the MK10DX128VFM5?
The package type is 32-QFN (5 mm x 5 mm).
