Overview
The 74LV4052PW/AU118 is a dual single-pole quad-throw analog switch, designed and manufactured by NXP USA Inc. This component is suitable for use in 4:1 multiplexer/demultiplexer applications, making it a versatile tool in various electronic systems. It is part of NXP's extensive portfolio of analog switches, which are known for their reliability and performance in a wide range of industrial and automotive applications.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | 74LV4052PW/AU118 |
| Manufacturer | NXP USA Inc. |
| Description | Dual 4-channel analog multiplexer/demultiplexer |
| Package | 16-TSSOP |
| Switch Type | Single-pole quad-throw |
| Number of Channels | 4 |
| On Resistance | 85 Ohm |
| Voltage Range | -0.5 V to 6.0 V |
Key Features
- Dual 4-channel operation: Allows for two independent 4:1 multiplexer/demultiplexer channels.
- Low on-resistance: 85 Ohm, ensuring minimal signal attenuation.
- Wide voltage range: Operates from -0.5 V to 6.0 V, making it versatile for various applications.
- Compact 16-TSSOP package: Suitable for space-constrained designs.
- High reliability: Part of NXP's reliable and performance-driven product line.
Applications
- Industrial automation: Used in control systems, data acquisition, and signal processing.
- Automotive systems: Suitable for use in vehicle control units, infotainment systems, and safety features.
- Medical devices: Can be used in medical equipment for signal switching and multiplexing.
- Telecommunications: Applied in telecommunications equipment for signal routing and switching.
- Consumer electronics: Used in various consumer devices requiring analog signal switching.
Q & A
- What is the primary function of the 74LV4052PW/AU118?
The primary function is to act as a dual 4-channel analog multiplexer/demultiplexer.
- Who is the manufacturer of this component?
NXP USA Inc.
- What is the package type of the 74LV4052PW/AU118?
16-TSSOP (Thin Shrink Small Outline Package).
- What is the on-resistance of the 74LV4052PW/AU118?
85 Ohm.
- What is the voltage range for the 74LV4052PW/AU118?
-0.5 V to 6.0 V.
- In which industries is the 74LV4052PW/AU118 commonly used?
Industrial automation, automotive, medical devices, telecommunications, and consumer electronics.
- How many channels does the 74LV4052PW/AU118 have?
It has two independent 4-channel multiplexer/demultiplexer channels.
- What makes the 74LV4052PW/AU118 suitable for space-constrained designs?
Its compact 16-TSSOP package.
- Is the 74LV4052PW/AU118 part of a reliable product line?
Yes, it is part of NXP's reliable and performance-driven product line.
- Where can I purchase the 74LV4052PW/AU118?
It can be purchased from various electronic component distributors such as Digi-Key, Mouser, and Avnet.
