Overview
The 74HCT125PW-Q100118 is a quad buffer/line driver with 3-state outputs, manufactured by NXP USA Inc. (now part of Nexperia). This component is designed to provide reliable signal buffering and driving capabilities in various electronic systems. It is particularly suited for automotive applications due to its qualification to the Automotive Electronics Council (AEC) standard Q100 (Grade 1). The device operates within a wide supply voltage range from 2.0 V to 6.0 V and is specified to function from -40 °C to +125 °C, making it versatile for different environmental conditions.
Key Specifications
| Parameter | Value |
|---|---|
| Type Number | 74HCT125PW-Q100118 |
| Logic Device Type | Buffer, Line Driver |
| Logic Family / Base Number | 74HCT125 |
| IC Case / Package | TSSOP-14 |
| No. of Pins | 14 |
| Supply Voltage Min | 4.5 V |
| Supply Voltage Max | 5.5 V |
| Operating Temperature Min | -40 °C |
| Operating Temperature Max | 125 °C |
| Output Drive Capability | ± 6 mA |
| Output Type | 3-State |
| Logic Switching Levels | TTL |
| Qualification | AEC-Q100 (Grade 1) |
Key Features
- Wide Supply Voltage Range: Operates from 2.0 V to 6.0 V, making it compatible with various system voltages.
- High Noise Immunity: Ensures reliable operation in noisy environments.
- Low Power Dissipation: CMOS technology reduces power consumption.
- 3-State Outputs: Controlled by output enable inputs (nOE), allowing for high impedance OFF-state when nOE is HIGH.
- Automotive Qualification: Qualified to AEC-Q100 (Grade 1) for use in automotive applications.
- Latch-up Performance: Exceeds 100 mA per JESD 78 Class II Level B.
- ESD Protection: HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V, CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V.
Applications
- Automotive Systems: Suitable for use in automotive electronics due to its AEC-Q100 qualification.
- Industrial Control Systems: Can be used in industrial control systems requiring reliable signal buffering and driving.
- Consumer Electronics: Applicable in consumer electronics where low power consumption and high noise immunity are necessary.
- Embedded Systems: Useful in embedded systems that require 3-state output capabilities and wide supply voltage range.
Q & A
- What is the primary function of the 74HCT125PW-Q100118?
The primary function is to act as a quad buffer/line driver with 3-state outputs.
- What is the supply voltage range for this component?
The supply voltage range is from 2.0 V to 6.0 V.
- What are the operating temperature limits for this component?
The operating temperature range is from -40 °C to +125 °C.
- What is the logic switching level for this component?
The logic switching level is TTL (Transistor-Transistor Logic).
- Is this component qualified for automotive use?
Yes, it is qualified to the Automotive Electronics Council (AEC) standard Q100 (Grade 1).
- What is the output drive capability of this component?
The output drive capability is ± 6 mA.
- What type of package does this component use?
The component is packaged in a TSSOP-14.
- Does this component have ESD protection?
Yes, it has ESD protection exceeding 2000 V for HBM and 1000 V for CDM.
- What is the latch-up performance of this component?
The latch-up performance exceeds 100 mA per JESD 78 Class II Level B.
- Is this component RoHS compliant?
Yes, it is RoHS compliant.
