Overview
The BZX84J-B5V6/DG/B2 is a general-purpose Zener diode produced by Nexperia USA Inc. Although this specific part is listed as obsolete and no longer manufactured, it is part of the broader BZX84 series, which is widely used for voltage regulation. These diodes are designed to provide stable voltage references in a variety of applications.
The BZX84 series includes diodes with nominal working voltages ranging from 2.4 V to 75 V, available in different tolerance ranges (±1%, ±2%, and ±5%). The BZX84J-B5V6/DG/B2, specifically, would have been part of this range, offering a nominal Zener voltage of 5.6 V with a ±5% tolerance.
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| Nominal Zener Voltage (VZ) | 5.6 | V |
| Zener Voltage Tolerance | ±5% | - |
| Maximum Zener Current (IZ) | 5 | mA |
| Maximum Forward Current (IF) | 200 | mA |
| Total Power Dissipation (Ptot) | 250 | mW |
| Non-Repetitive Peak Reverse Power Dissipation (PZSM) | 40 | W |
| Junction Temperature (TJ) | -55 to 150 | °C |
| Package Type | SOD323F (SC-90) | - |
Key Features
- Low-power voltage regulator diodes in a small SOD323F (SC-90) Surface-Mounted Device (SMD) plastic package.
- Nominal working voltages from 2.4 V to 75 V, with the BZX84J-B5V6/DG/B2 specifically at 5.6 V.
- Available in three tolerance series: ±1% (BZX84-A), ±2% (BZX84-B), and ±5% (BZX84-C).
- Total power dissipation of up to 250 mW.
- Non-repetitive peak reverse power dissipation of up to 40 W.
- Junction temperature range from -55°C to 150°C.
Applications
- General voltage regulation functions.
- Voltage stabilization in power supplies and electronic circuits.
- Overvoltage protection and surge absorption.
- Automotive and industrial applications requiring stable voltage references.
Q & A
- What is the nominal Zener voltage of the BZX84J-B5V6/DG/B2?
The nominal Zener voltage is 5.6 V.
- What is the tolerance range for the BZX84J-B5V6/DG/B2?
The tolerance range is ±5%.
- What is the maximum Zener current for this diode?
The maximum Zener current is 5 mA.
- What is the total power dissipation of the BZX84J-B5V6/DG/B2?
The total power dissipation is up to 250 mW.
- What is the junction temperature range for this diode?
The junction temperature range is from -55°C to 150°C.
- In what package type is the BZX84J-B5V6/DG/B2 available?
The diode is available in a SOD323F (SC-90) package.
- What are some common applications for the BZX84 series diodes?
Common applications include general voltage regulation, voltage stabilization, overvoltage protection, and automotive and industrial applications.
- Is the BZX84J-B5V6/DG/B2 still in production?
No, the BZX84J-B5V6/DG/B2 is listed as obsolete and is no longer manufactured.
- What are the available tolerance series for the BZX84 series?
The BZX84 series is available in ±1%, ±2%, and ±5% tolerance ranges.
- What is the non-repetitive peak reverse power dissipation for this diode?
The non-repetitive peak reverse power dissipation is up to 40 W.
