Overview
The 74LVC1G08GM-Q100X, produced by Nexperia USA Inc., is a single 2-input AND gate integrated circuit. This device is designed to operate in a wide range of supply voltages from 1.65 V to 5.5 V, making it versatile for various applications. It features Schmitt trigger action at all inputs, which enhances noise immunity and tolerance to slower input rise and fall times. The 74LVC1G08GM-Q100X is also qualified to the Automotive Electronics Council (AEC) standard Q100 (Grade 1), ensuring its suitability for automotive and other demanding environments.
Key Specifications
| Type number | VCC (V) | Logic switching levels | Output drive capability (mA) | tpd (ns) | fmax (MHz) | Nr of bits | Power dissipation considerations | Tamb (°C) | Package name |
|---|---|---|---|---|---|---|---|---|---|
| 74LVC1G08GM | 1.65 - 5.5 | CMOS/LVTTL | ± 24 | 2.1 | 150 | 1 | low | -40 to +125 | XSON6 (SOT886) |
Key Features
- Wide supply voltage range from 1.65 V to 5.5 V, allowing operation with both 3.3 V and 5 V devices.
- Schmitt trigger action at all inputs for high noise immunity and tolerance to slower input rise and fall times.
- Automotive product qualification in accordance with AEC-Q100 (Grade 1), suitable for automotive applications.
- IOFF circuitry for partial power-down applications, preventing damaging backflow current when the device is powered down.
- High output drive capability of ±24 mA at VCC = 3.0 V.
Applications
The 74LVC1G08GM-Q100X is suitable for a variety of applications, including:
- Automotive systems, due to its AEC-Q100 qualification.
- Mixed 3.3 V and 5 V applications, serving as a translator.
- Industrial and consumer electronics where high noise immunity and robust operation are required.
- Power management and control circuits in various electronic devices.
Q & A
- What is the primary function of the 74LVC1G08GM-Q100X? The primary function is to act as a single 2-input AND gate.
- What is the supply voltage range for this device? The supply voltage range is from 1.65 V to 5.5 V.
- Does the 74LVC1G08GM-Q100X support partial power-down applications? Yes, it features IOFF circuitry for partial power-down applications.
- What is the output drive capability of the 74LVC1G08GM-Q100X? The output drive capability is ±24 mA at VCC = 3.0 V.
- Is the 74LVC1G08GM-Q100X suitable for automotive applications? Yes, it is qualified to the AEC-Q100 (Grade 1) standard.
- What type of package does the 74LVC1G08GM-Q100X come in? It comes in an XSON6 (SOT886) package.
- What is the operating temperature range for this device? The operating temperature range is from -40 °C to +125 °C.
- Does the 74LVC1G08GM-Q100X have Schmitt trigger action? Yes, it features Schmitt trigger action at all inputs.
- Can the 74LVC1G08GM-Q100X be used in mixed 3.3 V and 5 V applications? Yes, it can be used as a translator in such applications.
- What is the maximum frequency of operation for the 74LVC1G08GM-Q100X? The maximum frequency of operation is 150 MHz.
