Overview
The MAX1338ETN+T, produced by Analog Devices Inc./Maxim Integrated, is a 14-bit, 4-channel, software-programmable, multiranging analog-to-digital converter (ADC). This device is designed to offer high precision and flexibility, making it suitable for a variety of applications that require simultaneous sampling of multiple analog signals. The MAX1338 features an on-board oscillator and a 2.5V internal reference, with the option to use an external clock and/or reference if needed. It operates from a +5V supply voltage and is housed in a 56-WFQFN exposed pad package.
Key Specifications
| Parameter | Value |
|---|---|
| Number of ADC Inputs | 4 Input |
| Number of Converters | 1 Converter |
| Resolution | 14-bit |
| Operating Supply Voltage | 4.75V ~ 5.25V |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 56-WFQFN Exposed Pad |
| Length | 8 mm |
Key Features
- Simultaneous sampling of four fully differential input channels
- Independent track-and-hold (T/H) circuits for each channel
- Software-programmable multiranging capability
- On-board oscillator and 2.5V internal reference with options for external clock and/or reference
- High accuracy and low noise performance
Applications
The MAX1338ETN+T is suitable for various applications requiring high-precision, simultaneous sampling of multiple analog signals. These include industrial control systems, medical devices, data acquisition systems, and any application where precise and simultaneous measurement of multiple analog inputs is necessary.
Q & A
- What is the resolution of the MAX1338ETN+T ADC?
The MAX1338ETN+T has a resolution of 14 bits. - How many input channels does the MAX1338ETN+T have?
The MAX1338ETN+T has four simultaneously sampled, fully differential input channels. - What is the operating supply voltage range for the MAX1338ETN+T?
The operating supply voltage range is 4.75V ~ 5.25V. - What is the operating temperature range for the MAX1338ETN+T?
The operating temperature range is -40°C ~ 85°C. - What type of package does the MAX1338ETN+T come in?
The MAX1338ETN+T is housed in a 56-WFQFN exposed pad package. - Does the MAX1338ETN+T support external clock and reference options?
Yes, the MAX1338ETN+T supports the use of an external clock and/or reference. - What are some typical applications for the MAX1338ETN+T?
Typical applications include industrial control systems, medical devices, and data acquisition systems. - Does the MAX1338ETN+T have independent track-and-hold circuits for each channel?
Yes, the MAX1338ETN+T has independent track-and-hold (T/H) circuits for each channel. - Is the MAX1338ETN+T software-programmable?
Yes, the MAX1338ETN+T is software-programmable, allowing for multiranging capability. - What is the length of the MAX1338ETN+T package?
The length of the package is 8 mm.
