Overview
The MAX1211ETL+ is a high-performance, 12-bit analog-to-digital converter (ADC) produced by Analog Devices Inc./Maxim Integrated. This device operates at a supply voltage of 3.3V and features a fully differential wideband track-and-hold (T/H) input. It is designed for high-speed applications, supporting a sampling rate of up to 65 Msps. The MAX1211ETL+ is housed in a 40-WFQFN Exposed Pad package, making it suitable for a variety of industrial and commercial environments with an operating temperature range of -40°C to 85°C.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 12-bit |
| Sampling Rate | Up to 65 Msps |
| Supply Voltage | 3.3V |
| Operating Temperature | -40°C to 85°C |
| Package | 40-WFQFN Exposed Pad |
| Input Type | Fully differential wideband track-and-hold (T/H) |
Key Features
- Fully differential wideband track-and-hold (T/H) input
- High sampling rate of up to 65 Msps
- Low power consumption
- Operating supply voltage of 3.3V
- Wide operating temperature range of -40°C to 85°C
- Compact 40-WFQFN Exposed Pad package
Applications
The MAX1211ETL+ is suitable for various high-speed data acquisition applications, including:
- IF sampling in communication systems
- Medical imaging and diagnostics
- Aerospace and defense systems
- Industrial automation and control systems
- High-speed data acquisition systems
Q & A
- What is the resolution of the MAX1211ETL+ ADC?
The MAX1211ETL+ has a resolution of 12 bits. - What is the maximum sampling rate of the MAX1211ETL+?
The MAX1211ETL+ can sample up to 65 Msps. - What is the supply voltage for the MAX1211ETL+?
The supply voltage for the MAX1211ETL+ is 3.3V. - What is the operating temperature range of the MAX1211ETL+?
The operating temperature range is -40°C to 85°C. - What type of package does the MAX1211ETL+ come in?
The MAX1211ETL+ is housed in a 40-WFQFN Exposed Pad package. - What type of input does the MAX1211ETL+ have?
The MAX1211ETL+ features a fully differential wideband track-and-hold (T/H) input. - Is the MAX1211ETL+ suitable for high-speed applications?
Yes, the MAX1211ETL+ is designed for high-speed applications. - What are some common applications for the MAX1211ETL+?
Common applications include IF sampling in communication systems, medical imaging, aerospace and defense systems, industrial automation, and high-speed data acquisition systems. - Where can I find detailed specifications for the MAX1211ETL+?
Detailed specifications can be found on the official Analog Devices website, as well as on distributor websites like Digi-Key and Mouser. - Is the MAX1211ETL+ suitable for industrial environments?
Yes, the MAX1211ETL+ is suitable for industrial environments due to its wide operating temperature range and robust design.
