Analog Devices Inc. LTC2150IUJ-14#PBF

Manufacturer No:
LTC2150IUJ-14#PBF
Manufacturer:
Analog Devices Inc.
Package:
Tube
Description:
IC ADC 14BIT PIPELINED 40QFN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The LTC2150IUJ-14#PBF is a high-performance, 14-bit analog-to-digital converter (ADC) produced by Analog Devices Inc. This device is part of the LTC2150 family and is known for its high-speed conversion capabilities and low power consumption. It is packaged in a 40-lead QFN (Quad Flat No-Lead) package, making it suitable for a variety of applications requiring high precision and speed.

Key Specifications

ParameterValue
Resolution14 bits
Sampling RateUp to 170 Msps
Package Type40-Lead QFN
InterfaceParallel, Serial (SPI), LVDS
Power ConsumptionTypically 1.1 W at 170 Msps
Operating Temperature Range-40°C to 85°C
RoHS ComplianceYes

Key Features

  • High-speed conversion up to 170 Msps
  • Low power consumption, typically 1.1 W at 170 Msps
  • High dynamic performance with SNR of up to 73.5 dBFS and SFDR of up to 90 dBFS
  • Flexible interface options including parallel, serial (SPI), and LVDS
  • Compact 40-lead QFN package
  • RoHS compliant

Applications

  • Wireless communication systems
  • Radar and electronic warfare systems
  • Medical imaging and diagnostics
  • High-speed data acquisition systems
  • Test and measurement equipment

Q & A

  1. What is the resolution of the LTC2150IUJ-14#PBF ADC?
    The LTC2150IUJ-14#PBF has a resolution of 14 bits.
  2. What is the maximum sampling rate of the LTC2150IUJ-14#PBF?
    The maximum sampling rate is up to 170 Msps.
  3. What package type is the LTC2150IUJ-14#PBF available in?
    The device is packaged in a 40-lead QFN package.
  4. What interfaces does the LTC2150IUJ-14#PBF support?
    The device supports parallel, serial (SPI), and LVDS interfaces.
  5. Is the LTC2150IUJ-14#PBF RoHS compliant?
    Yes, the LTC2150IUJ-14#PBF is RoHS compliant.
  6. What is the typical power consumption of the LTC2150IUJ-14#PBF at 170 Msps?
    The typical power consumption is 1.1 W at 170 Msps.
  7. What is the operating temperature range of the LTC2150IUJ-14#PBF?
    The operating temperature range is -40°C to 85°C.
  8. What are some common applications of the LTC2150IUJ-14#PBF?
    Common applications include wireless communication systems, radar and electronic warfare systems, medical imaging, high-speed data acquisition systems, and test and measurement equipment.
  9. Where can I find detailed specifications and datasheets for the LTC2150IUJ-14#PBF?
    Detailed specifications and datasheets can be found on the official Analog Devices website and through distributors like Digi-Key and Mouser.
  10. Is the LTC2150IUJ-14#PBF suitable for high-speed data acquisition?
    Yes, the LTC2150IUJ-14#PBF is highly suitable for high-speed data acquisition due to its high sampling rate and low power consumption.

Product Attributes

Number of Bits:14
Sampling Rate (Per Second):170M
Number of Inputs:1
Input Type:Differential
Data Interface:LVDS - Parallel
Configuration:S/H-ADC
Ratio - S/H:ADC:1:1
Number of A/D Converters:1
Architecture:Pipelined
Reference Type:External, Internal
Voltage - Supply, Analog:1.7V ~ 1.9V
Voltage - Supply, Digital:1.7V ~ 1.9V
Features:-
Operating Temperature:-40°C ~ 85°C
Package / Case:40-WFQFN Exposed Pad
Supplier Device Package:40-QFN (6x6)
Mounting Type:Surface Mount
