Overview
The ADUC814ARUZ-REEL7 is a microcontroller from Analog Devices' MicroConverter series, integrating high-performance analog I/O with digital processing capabilities. This 8-bit microcontroller is based on the 8052 core architecture and is designed for applications requiring a blend of analog and digital functionality.
It features an internal oscillator, various communication interfaces, and a range of peripherals, making it suitable for a variety of industrial, household, security monitoring, and medical equipment applications.
Key Specifications
| Attribute | Value |
|---|---|
| Manufacturer | Analog Devices |
| Part Number | ADUC814ARUZ-REEL7 |
| Core Architecture | 8052 |
| Core Size | 8-Bit |
| Speed | 16.78 MHz |
| Package/Case | 28-TSSOP |
| Number of Pins | 28 |
| Number of I/Os | 17 |
| Memory Type | FLASH |
| Program Memory Size | 8 KB (8K x 8) |
| EEPROM Size | 640 x 8 |
| RAM Size | 256 x 8 |
| Supply Voltage | 2.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Interface | I2C, SPI, UART/USART |
| Peripherals | POR, PSM, Temp Sensor, WDT |
| Data Converters | 6x12b ADC, 2x12b DAC |
| Oscillator Type | Internal |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
Key Features
- 8052 Core Processor: Provides a robust 8-bit core architecture.
- Analog and Digital Capabilities: Includes 6-channel 12-bit analog-to-digital converters (ADCs) and 2-channel 12-bit digital-to-analog converters (DACs).
- Communication Interfaces: Supports I2C, SPI, and UART/USART for versatile communication options.
- Peripherals: Features Power-On Reset (POR), Power Save Mode (PSM), integrated temperature sensor, and watchdog timer (WDT).
- Memory: Equipped with 8 KB of FLASH program memory, 640 bytes of EEPROM, and 256 bytes of RAM.
- Internal Oscillator: Reduces the need for external components.
- General Purpose I/O Pins: Offers 17 general purpose I/O pins for flexibility in application design.
Applications
- Industrial Control Systems: Suitable for various industrial automation and control applications.
- Household Appliances: Can be used in smart home devices and other household electronics.
- Security Monitoring Systems: Ideal for security and surveillance systems due to its integrated analog and digital capabilities.
- Medical Equipment: Used in medical devices that require precise analog and digital processing.
Q & A
- What is the core architecture of the ADUC814ARUZ-REEL7?
The ADUC814ARUZ-REEL7 is based on the 8052 core architecture.
- What is the maximum operating frequency of the ADUC814ARUZ-REEL7?
The maximum operating frequency is 16.78 MHz.
- What types of communication interfaces does the ADUC814ARUZ-REEL7 support?
The ADUC814ARUZ-REEL7 supports I2C, SPI, and UART/USART interfaces.
- What is the memory configuration of the ADUC814ARUZ-REEL7?
The device has 8 KB of FLASH program memory, 640 bytes of EEPROM, and 256 bytes of RAM.
- Does the ADUC814ARUZ-REEL7 have any integrated peripherals?
Yes, it includes Power-On Reset (POR), Power Save Mode (PSM), an integrated temperature sensor, and a watchdog timer (WDT).
- What is the operating temperature range of the ADUC814ARUZ-REEL7?
The operating temperature range is -40°C to 125°C.
- What is the packaging type of the ADUC814ARUZ-REEL7?
The device is packaged in a 28-TSSOP and is available in tape and reel (TR) format.
- Is the ADUC814ARUZ-REEL7 RoHS compliant?
Yes, the ADUC814ARUZ-REEL7 is RoHS compliant.
- How many ADC and DAC channels does the ADUC814ARUZ-REEL7 have?
The device has 6-channel 12-bit ADCs and 2-channel 12-bit DACs.
- Does the ADUC814ARUZ-REEL7 have an internal oscillator?
Yes, it has an internal oscillator.
