Overview
The AD9411BSVZ-170 is a high-performance, 10-bit analog-to-digital converter (ADC) produced by Analog Devices Inc. This component is designed for high-speed applications, offering sampling rates of up to 170 MSPS. It is part of the AD9411 series, known for its high integration and efficiency, making it suitable for a variety of demanding electronic systems.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | AD9411BSVZ-170 |
| Manufacturer | Analog Devices Inc. |
| Resolution | 10-bit |
| Sampling Rate | Up to 170 MSPS |
| Supply Voltage | 3.3 V |
| Operating Temperature Range | -40°C to +85°C |
| Package Type | 100-Lead Thin Quad Flat Package (TQFP), Exposed Pad |
Key Features
- High-Speed Conversion: Supports sampling rates up to 170 MSPS, making it ideal for high-speed data acquisition applications.
- Low Power Consumption: Optimized for low power consumption relative to its high performance, which is beneficial for power-sensitive designs.
- High Integration: Reduces the overall system component count by integrating multiple functions into a single chip.
- Compact Packaging: Uses a 100-Lead Thin Quad Flat Package (TQFP) with an exposed pad, which is compact and suitable for space-sensitive applications.
- Robust Design: Manufactured according to Analog Devices' strict quality standards, ensuring long-term reliability and resilience to environmental stressors.
Applications
- High-Speed Data Acquisition: Suitable for applications requiring rapid data conversion, such as in medical imaging, radar systems, and high-speed test and measurement equipment.
- Communication Systems: Used in wireless communication systems, satellite communications, and other high-speed communication applications.
- Industrial Automation: Applied in industrial control systems, process control, and other automation environments where high-speed data conversion is necessary.
- Aerospace and Defense: Utilized in various military and aerospace applications where high reliability and performance are critical.
Q & A
- What is the sampling rate of the AD9411BSVZ-170?
The AD9411BSVZ-170 has a sampling rate of up to 170 MSPS.
- What is the resolution of the AD9411BSVZ-170?
The AD9411BSVZ-170 is a 10-bit analog-to-digital converter.
- What is the supply voltage for the AD9411BSVZ-170?
The supply voltage for the AD9411BSVZ-170 is 3.3 V.
- What is the operating temperature range of the AD9411BSVZ-170?
The operating temperature range is -40°C to +85°C.
- What type of package does the AD9411BSVZ-170 use?
The AD9411BSVZ-170 uses a 100-Lead Thin Quad Flat Package (TQFP) with an exposed pad.
- Is the AD9411BSVZ-170 suitable for high-speed data acquisition applications?
Yes, it is highly suitable due to its high sampling rate and low power consumption.
- What are some common applications of the AD9411BSVZ-170?
Common applications include high-speed data acquisition, communication systems, industrial automation, and aerospace and defense.
- How does the AD9411BSVZ-170 contribute to system design efficiency?
It reduces the overall system component count through high integration and uses a compact package, making it efficient for space-sensitive designs.
- What are the benefits of using the AD9411BSVZ-170 in terms of reliability?
The component is manufactured according to Analog Devices' strict quality standards, ensuring long-term reliability and resilience to environmental stressors.
- Can the AD9411BSVZ-170 be used in power-sensitive designs?
Yes, it is optimized for low power consumption relative to its high performance.
