Overview
The AD5680BRJZ-1500RL7 is a high-performance, single-channel 18-bit digital-to-analog converter (DAC) produced by Analog Devices Inc. This component is part of the nanoDAC family and is known for its compact size and high accuracy. The AD5680BRJZ-1500RL7 operates on a single 5V supply and is housed in a tiny 8-lead SOT-23 package, making it ideal for space-constrained applications.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 18 bits |
| Accuracy | 12-bit guaranteed monotonic |
| Supply Voltage | 5 V |
| Package Type | 8-lead SOT-23 |
| Operating Temperature Range | -40°C to +105°C |
| Interface | SPI-compatible serial interface |
Key Features
- Single 18-bit nanoDAC with 12-bit guaranteed monotonicity
- Tiny 8-lead SOT-23 package for space-saving designs
- Operates on a single 5V supply
- SPI-compatible serial interface for easy communication
- Low power consumption
- High accuracy and reliability
Applications
The AD5680BRJZ-1500RL7 is suitable for a variety of applications where high precision and compact size are crucial. These include industrial control systems, medical devices, automotive systems, and any other application requiring accurate digital-to-analog conversion in a small form factor.
Q & A
- What is the resolution of the AD5680BRJZ-1500RL7?
The AD5680BRJZ-1500RL7 has a resolution of 18 bits. - What is the guaranteed accuracy of the AD5680BRJZ-1500RL7?
The AD5680BRJZ-1500RL7 has a guaranteed accuracy of 12-bit monotonicity. - What is the supply voltage for the AD5680BRJZ-1500RL7?
The AD5680BRJZ-1500RL7 operates on a single 5V supply. - What package type is the AD5680BRJZ-1500RL7 available in?
The AD5680BRJZ-1500RL7 is available in an 8-lead SOT-23 package. - What is the operating temperature range of the AD5680BRJZ-1500RL7?
The operating temperature range of the AD5680BRJZ-1500RL7 is -40°C to +105°C. - What type of interface does the AD5680BRJZ-1500RL7 use?
The AD5680BRJZ-1500RL7 uses an SPI-compatible serial interface. - Is the AD5680BRJZ-1500RL7 suitable for industrial control systems?
Yes, the AD5680BRJZ-1500RL7 is suitable for industrial control systems due to its high accuracy and compact size. - Can the AD5680BRJZ-1500RL7 be used in medical devices?
Yes, the AD5680BRJZ-1500RL7 can be used in medical devices where high precision is required. - What are some other applications for the AD5680BRJZ-1500RL7?
Other applications include automotive systems and any other application requiring accurate digital-to-analog conversion in a small form factor. - Where can I find detailed specifications for the AD5680BRJZ-1500RL7?
Detailed specifications can be found in the datasheet available on the Analog Devices website or through distributors like Digi-Key and Mouser.
