Overview
The 5962-8965401XA is an 8-bit analog-to-digital converter (ADC) manufactured by Analog Devices Inc. This component is designed for high-speed data acquisition and conversion, making it suitable for various applications requiring precise and rapid analog-to-digital conversion.
It is part of the military-grade components, ensuring high reliability and performance under extreme conditions. The ADC features a sampling rate of up to 100 Msps, making it ideal for applications that demand high-speed data processing.
Key Specifications
| Category | Description |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Part Number | 5962-8965401XA |
| Resolution | 8 bits |
| Sampling Rate | Up to 100 Msps |
| Operating Temperature Range | -55°C to 125°C |
| Package Type | 40-CDIP (0.600", 15.24mm) |
| Mounting Style | Through Hole |
| Data Interface | Parallel |
| Input Type | Differential |
| Supply Voltage | ±10.8 V ~ 13.2 V |
Key Features
- High-Speed Conversion: The ADC operates at a sampling rate of up to 100 Msps, making it suitable for high-speed data acquisition applications.
- High Resolution: Although it is an 8-bit converter, it provides reliable and accurate conversions within its specified range.
- Wide Operating Temperature Range: The component can operate in extreme temperatures from -55°C to 125°C, ensuring reliability in harsh environments.
- Parallel Data Interface: It uses a parallel data interface, which is beneficial for applications requiring fast data transfer.
- Differential Input: The ADC supports differential input, which helps in reducing noise and improving signal integrity.
Applications
- Military and Aerospace: Given its military-grade specifications and wide operating temperature range, it is ideal for use in military and aerospace applications.
- High-Speed Data Acquisition Systems: The high sampling rate makes it suitable for systems that require rapid data acquisition and processing.
- Industrial Automation: It can be used in industrial automation systems where high-speed and accurate data conversion is necessary.
- Medical Devices: The component's reliability and accuracy make it a candidate for use in medical devices that require precise data conversion.
Q & A
- What is the resolution of the 5962-8965401XA ADC?
The resolution of the 5962-8965401XA ADC is 8 bits.
- What is the maximum sampling rate of the 5962-8965401XA?
The maximum sampling rate is up to 100 Msps.
- What is the operating temperature range of the 5962-8965401XA?
The operating temperature range is from -55°C to 125°C.
- What type of data interface does the 5962-8965401XA use?
The 5962-8965401XA uses a parallel data interface.
- What is the package type of the 5962-8965401XA?
The package type is 40-CDIP (0.600", 15.24mm).
- Is the 5962-8965401XA suitable for use in harsh environments?
Yes, it is suitable for use in harsh environments due to its wide operating temperature range and military-grade specifications.
- What type of input does the 5962-8965401XA support?
The 5962-8965401XA supports differential input.
- What are the typical applications of the 5962-8965401XA?
Typical applications include military and aerospace, high-speed data acquisition systems, industrial automation, and medical devices.
- What is the supply voltage range for the 5962-8965401XA?
The supply voltage range is ±10.8 V ~ 13.2 V.
- Is the 5962-8965401XA RoHS compliant?
While specific RoHS compliance details for this part are not provided, it is generally recommended to check the latest documentation from the manufacturer or authorized distributors for the most current information.
