Overview
The TS3DV642A0RUAR is a dual 2:1 multiplexer/demultiplexer switch produced by Texas Instruments. This component is designed to manage signal routing in various electronic systems, providing a flexible and reliable solution for signal switching needs.
Key Specifications
| Parameter | Value |
|---|---|
| Number of Channels | 2 |
| Switch Type | 2:1 Multiplexer/Demultiplexer |
| Supply Voltage | 1.65V to 5.5V |
| Operating Temperature | -40°C to 125°C |
| Package Type | UQFN-10 |
| Pins | 10 |
Key Features
- Dual 2:1 multiplexer/demultiplexer configuration
- Low ON-state resistance (RON) for minimal signal distortion
- High OFF-state isolation
- Low power consumption
- Wide operating voltage range (1.65V to 5.5V)
- Compact UQFN-10 package
Applications
The TS3DV642A0RUAR is suitable for various applications requiring signal routing and switching, including:
- Audio and video signal switching
- Data communication systems
- Industrial control systems
- Medical devices
- Consumer electronics
Q & A
- What is the primary function of the TS3DV642A0RUAR? The primary function is to act as a dual 2:1 multiplexer/demultiplexer switch.
- What is the operating voltage range of the TS3DV642A0RUAR? The operating voltage range is from 1.65V to 5.5V.
- What is the package type of the TS3DV642A0RUAR? The package type is UQFN-10.
- What are the key features of the TS3DV642A0RUAR? Key features include low ON-state resistance, high OFF-state isolation, low power consumption, and a wide operating voltage range.
- Where can I find the datasheet for the TS3DV642A0RUAR? You can download the datasheet from the Texas Instruments website or through distributors like Octopart.
- What are some common applications for the TS3DV642A0RUAR? Common applications include audio and video signal switching, data communication systems, industrial control systems, medical devices, and consumer electronics.
- How many channels does the TS3DV642A0RUAR have? The TS3DV642A0RUAR has 2 channels.
- What is the operating temperature range of the TS3DV642A0RUAR? The operating temperature range is from -40°C to 125°C.
- Is the TS3DV642A0RUAR suitable for high-frequency applications? Yes, it is suitable due to its low ON-state resistance and high OFF-state isolation.
- Where can I purchase the TS3DV642A0RUAR? You can purchase it from various distributors such as Digi-Key, Mouser, and Arrow Electronics.
