Overview
The SN74LV125ARGYRG4 is a quad bus buffer gate with 3-state outputs, manufactured by Texas Instruments. It belongs to the 74LV series and is designed for use in digital logic applications. This component is particularly suited for applications requiring signal buffering and line driving in low-voltage environments. Its market positioning targets industries such as industrial automation, consumer electronics, and automotive electronics, where reliable and efficient signal management is crucial. The SN74LV125ARGYRG4 stands out for its low power consumption, wide operating voltage range, and robust performance in harsh environmental conditions.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Category | Logic - Buffers, Drivers, Receivers, Transceivers | ||
| Description | IC BUS BUFF TRI-ST QD 14VQFN | ||
| Series | 74LV | ||
| Manufacturer | Texas Instruments | ||
| Logic Type | Buffer/Line Driver, Non-Inverting | ||
| Number of Elements | 4 | ||
| Bits per Element | 1 | ||
| Output Current (High/Low) | 16mA, 16mA | ||
| Supply Voltage | 2 V ~ 5.5 V | ||
| Operating Temperature | -40°C ~ 85°C | ||
| Mounting Type | Surface Mount | ||
| Package/Case | 14-VFQFN Exposed Pad | ||
| Supplier Device Package | 14-VQFN Exposed Pad (3.5x3.5) | ||
| Packaging | Tape & Reel (TR) |
Key Features
- Quad bus buffer gate with 3-state outputs for efficient signal management.
- Wide operating voltage range (2 V to 5.5 V) for compatibility with various systems.
- Non-inverting logic type ensures signal integrity.
- Low power consumption, making it ideal for battery-powered applications.
- Robust performance in harsh environments with an operating temperature range of -40°C to 85°C.
- Compact 14-VQFN package for space-constrained designs.
Applications
The SN74LV125ARGYRG4 is widely used in various industries due to its reliable performance and versatility. In industrial automation, it is employed for signal buffering and line driving in control systems. In consumer electronics, it ensures efficient signal management in devices such as smartphones and tablets. The component is also utilized in automotive electronics for applications like sensor interfacing and communication modules. Its ability to operate in a wide voltage range and harsh conditions makes it a preferred choice for these fields.
Q & A
1. What is the operating voltage range of the SN74LV125ARGYRG4?
The operating voltage range is 2 V to 5.5 V.
2. What is the maximum output current of this component?
The maximum output current is 16 mA for both high and low states.
3. What is the operating temperature range of the SN74LV125ARGYRG4?
It operates within a temperature range of -40°C to 85°C.
4. What type of logic does this component use?
It uses non-inverting logic.
5. How many elements are there in the SN74LV125ARGYRG4?
There are 4 elements in this component.
6. What is the package type of the SN74LV125ARGYRG4?
It comes in a 14-VQFN exposed pad package.
7. Is this component suitable for automotive applications?
Yes, it is suitable for automotive electronics due to its robust performance and wide operating range.
8. What is the power consumption of the SN74LV125ARGYRG4?
It has low power consumption, making it ideal for battery-powered devices.
9. Can this component be used in industrial automation?
Yes, it is commonly used in industrial automation for signal buffering and line driving.
10. What is the packaging option for the SN74LV125ARGYRG4?
It is available in tape and reel (TR) packaging.
