Overview
The SN74CBT16211ADGGR is a high-speed TTL-compatible bus switch manufactured by Texas Instruments. Although this component is no longer in production, it remains relevant for understanding its capabilities and applications. The device provides 24 bits of bus switching, making it suitable for various integrated circuit applications. It is known for its low on-state resistance, which enhances its performance in high-speed switching scenarios.
Key Specifications
| Specification | Value |
|---|---|
| Manufacturer | Texas Instruments |
| Package Type | TSSOP-56 (6.1mm) |
| Number of Bits | 24 |
| Supply Voltage Range | 4.5V to 5.5V |
| On-State Resistance | Low on-state resistance |
| Compatibility | TTL-compatible |
| RoHS Compliance | Yes |
Key Features
- Provides 24 bits of high-speed TTL-compatible bus switching.
- Low on-state resistance for efficient switching.
- TSSOP-56 package with a 6.1mm footprint.
- Operates within a supply voltage range of 4.5V to 5.5V.
- RoHS compliant, ensuring environmental sustainability.
Applications
The SN74CBT16211ADGGR is primarily used in integrated circuit applications where high-speed bus switching is required. It is suitable for various digital systems, including:
- High-speed data transmission systems.
- Computer peripherals and networking equipment.
- Telecommunication devices.
- Industrial control systems.
Q & A
- What is the SN74CBT16211ADGGR used for?
The SN74CBT16211ADGGR is used for high-speed TTL-compatible bus switching in integrated circuits.
- Is the SN74CBT16211ADGGR still in production?
No, the SN74CBT16211ADGGR is no longer in production.
- What is the package type of the SN74CBT16211ADGGR?
The package type is TSSOP-56 with a 6.1mm footprint.
- What is the supply voltage range of the SN74CBT16211ADGGR?
The supply voltage range is from 4.5V to 5.5V.
- Is the SN74CBT16211ADGGR RoHS compliant?
Yes, the SN74CBT16211ADGGR is RoHS compliant.
- What are the key features of the SN74CBT16211ADGGR?
The key features include 24 bits of high-speed TTL-compatible bus switching, low on-state resistance, and a TSSOP-56 package.
- What are some common applications of the SN74CBT16211ADGGR?
Common applications include high-speed data transmission systems, computer peripherals, telecommunication devices, and industrial control systems.
- What is the on-state resistance of the SN74CBT16211ADGGR?
The on-state resistance is low, which enhances its performance in high-speed switching scenarios.
- Are there any substitutes for the SN74CBT16211ADGGR?
Yes, substitutes like the SN74CBT16211CDGGR are available and offer pin-for-pin compatibility.
- Where can I find detailed specifications for the SN74CBT16211ADGGR?
Detailed specifications can be found in the datasheet available on Texas Instruments' website or through distributors like Digi-Key and LCSC.
