Overview
The SN74AHCT08DGVR is a high-speed CMOS logic gate manufactured by Texas Instruments. It belongs to the 74AHCT series and is a quad 2-input AND gate. This component is designed for use in a wide range of digital logic applications, offering reliable performance and compatibility with TTL levels. Its compact package and low power consumption make it suitable for space-constrained and power-sensitive designs.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Technology Family | AHCT | - | High-speed CMOS |
| Supply Voltage (Min) | 4.5 | V | - |
| Supply Voltage (Max) | 5.5 | V | - |
| Number of Channels | 4 | - | Quad 2-input AND gates |
| Input Type | TTL-Compatible | - | - |
| Output Type | Push-Pull | - | - |
| Propagation Delay (Typ) | 7.5 | ns | @5V |
| Operating Temperature Range | 0 to 70 | °C | - |
| Package | TVSOP-14 | - | Compact form factor |
Key Features
- High-speed operation with a typical propagation delay of 7.5 ns.
- TTL-compatible inputs for easy integration with existing designs.
- Compact TVSOP-14 package for space-saving applications.
- Wide operating voltage range from 4.5V to 5.5V.
Applications
The SN74AHCT08DGVR is widely used in digital logic circuits, including signal processing, data selection, and control systems. Its reliability and performance make it suitable for applications in consumer electronics, industrial automation, and automotive electronics. Specifically, it can be used in microcontroller-based systems, data acquisition systems, and communication devices.
Q & A
1. What is the operating voltage range of the SN74AHCT08DGVR?
The operating voltage range is 4.5V to 5.5V.
2. Is the SN74AHCT08DGVR compatible with TTL logic levels?
Yes, it has TTL-compatible inputs.
3. What is the typical propagation delay of this component?
The typical propagation delay is 7.5 ns at 5V.
4. How many AND gates are included in the SN74AHCT08DGVR?
It includes four independent 2-input AND gates.
5. What is the package type of the SN74AHCT08DGVR?
It comes in a TVSOP-14 package.
6. What is the maximum operating temperature of this component?
The maximum operating temperature is 70°C.
7. Can this component be used in automotive applications?
Yes, it is suitable for automotive electronics due to its reliability.
8. What is the output type of the SN74AHCT08DGVR?
It has a push-pull output type.
9. Is the SN74AHCT08DGVR suitable for low-power applications?
Yes, its low power consumption makes it ideal for battery-operated devices.
10. What are the typical applications of this component?
Typical applications include digital logic circuits, signal processing, and control systems.
