Overview
The OPA2313IDRGT is a high-performance, low-power operational amplifier (op-amp) produced by Texas Instruments. This dual-channel op-amp is designed for a wide range of applications, offering excellent precision and efficiency. It is part of Texas Instruments' portfolio of analog ICs, targeting industries such as industrial automation, consumer electronics, and medical devices. The OPA2313IDRGT stands out for its ultra-low power consumption, rail-to-rail input/output operation, and small form factor, making it ideal for battery-powered and space-constrained applications.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Number of Channels | 2 | - | Dual-channel |
| Supply Voltage | 1.8 to 5.5 | V | Wide operating range |
| Quiescent Current | 17 | µA | Ultra-low power |
| Gain Bandwidth Product | 1 | MHz | High precision |
| Slew Rate | 0.6 | V/µs | Fast response |
| Input Offset Voltage | ±0.5 | mV | Low error |
| Operating Temperature Range | -40 to 125 | °C | Wide temperature range |
| Package | WSON-8 | - | Compact design |
Key Features
- Ultra-low power consumption for battery-powered applications.
- Rail-to-rail input/output for maximum dynamic range.
- Small form factor (WSON-8 package) ideal for space-constrained designs.
- High precision with low input offset voltage and low noise.
- Wide supply voltage range (1.8V to 5.5V) for versatile applications.
Applications
The OPA2313IDRGT is widely used in various industries due to its versatility and performance. In industrial automation, it is employed in signal conditioning and sensor interfacing. In consumer electronics, it enhances audio and signal processing in portable devices. Its low power consumption makes it suitable for medical devices such as wearable health monitors. Additionally, it is used in automotive electronics for precision control and measurement systems.
Q & A
1. What is the supply voltage range of the OPA2313IDRGT?
The supply voltage range is 1.8V to 5.5V.
2. Is the OPA2313IDRGT suitable for battery-powered devices?
Yes, its ultra-low quiescent current makes it ideal for battery-powered applications.
3. What is the operating temperature range?
It operates from -40°C to 125°C.
4. Does it support rail-to-rail operation?
Yes, it features rail-to-rail input and output.
5. What is the package type?
It comes in a WSON-8 package.
6. What is the gain bandwidth product?
The gain bandwidth product is 1 MHz.
7. Can it be used in medical devices?
Yes, its low power and precision make it suitable for medical applications.
8. What is the input offset voltage?
The input offset voltage is ±0.5 mV.
9. Is it suitable for audio applications?
Yes, its precision and low noise make it ideal for audio processing.
10. What is the quiescent current?
The quiescent current is 17 µA.
