Overview
The INA210BIRSWR is a high-precision, bidirectional current shunt monitor produced by Texas Instruments. It is designed for applications requiring accurate current sensing and monitoring. This component is part of Texas Instruments' extensive portfolio of analog devices, targeting industries such as industrial automation, automotive, and consumer electronics. Its compact size, high accuracy, and low power consumption make it a competitive choice for modern electronic designs.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Supply Voltage | 2.7 to 26 | V | |
| Current Sense Range | ±26 | V | |
| Accuracy | ±1% | Maximum error over temperature | |
| Quiescent Current | 60 | µA | |
| Operating Temperature | -40 to 125 | °C | |
| Package | SOT-23 | 6-pin |
Key Features
- High accuracy current sensing with ±1% maximum error.
- Wide supply voltage range from 2.7V to 26V.
- Low quiescent current of 60µA, ideal for power-sensitive applications.
- Bidirectional current sensing capability.
- Compact SOT-23 package for space-constrained designs.
Applications
The INA210BIRSWR is widely used in various industries due to its precision and reliability. In industrial automation, it is employed for motor control and power management systems. In automotive applications, it is used for battery monitoring and load detection. Additionally, it is suitable for consumer electronics, such as portable devices, where efficient power management is critical.
