Overview
The F280048PMQR is a high-performance 32-bit microcontroller (MCU) from Texas Instruments, designed for real-time control applications. It belongs to the C2000™ series, known for its precision and efficiency in digital signal processing. This model is particularly suited for industrial automation, automotive systems, and energy management, offering a blend of computational power and energy efficiency. Its unique selling points include a floating-point unit (FPU), trigonometric math unit (TMU), and extensive connectivity options, making it a versatile choice for complex control tasks.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Core | C28x | - | 32-bit architecture |
| Clock Speed | 100 | MHz | Max frequency |
| Flash Memory | 256 | KB | Program memory |
| RAM | 100 | KB | Data memory |
| ADC Resolution | 12 | bit | 3 channels |
| Operating Temperature | -40 to +125 | °C | Wide range |
| I/O Pins | 40 | - | Versatile connectivity |
| Package | LQFP | - | Compact form factor |
Key Features
- Integrated FPU and TMU for advanced mathematical operations.
- High-speed 12-bit ADC for precise analog signal processing.
- Extensive connectivity options including CAN, I2C, SPI, and UART.
- Robust design for industrial environments with a wide operating temperature range.
- Low power consumption for energy-efficient applications.
Applications
The F280048PMQR is widely used in various sectors due to its robust performance and versatility. In industrial automation, it drives precision control systems and machinery. In automotive electronics, it enhances vehicle control systems, including powertrain and body electronics. Additionally, it plays a crucial role in energy management systems, optimizing power usage and improving efficiency in renewable energy applications.
Q & A
What is the operating voltage range of the F280048PMQR?
The operating voltage ranges from 1.14V to 1.32V.
Can the F280048PMQR be used in automotive applications?
Yes, it is suitable for automotive control systems due to its robust design and wide temperature range.
What types of memory does the F280048PMQR have?
It includes 256 KB of flash memory and 100 KB of RAM.
Does the F280048PMQR support real-time control?
Yes, it is designed for real-time control applications with its C28x core and FPU.
What communication interfaces are available on the F280048PMQR?
It supports CAN, I2C, SPI, UART, and USB interfaces.
Is the F280048PMQR suitable for high-precision applications?
Yes, its 12-bit ADC and FPU make it ideal for high-precision tasks.
What is the maximum clock speed of the F280048PMQR?
The maximum clock speed is 100 MHz.
Can the F280048PMQR operate in harsh environments?
Yes, it can operate in temperatures ranging from -40°C to +125°C.
What is the package type of the F280048PMQR?
It comes in an LQFP package.
Does the F280048PMQR have a watchdog timer?
Yes, it includes a watchdog timer for system reliability.
