Overview
The ADC16DX370RMER is a high-performance, dual-channel, 16-bit analog-to-digital converter (ADC) produced by Texas Instruments. Designed for applications requiring high-speed data acquisition, this ADC operates at a sampling rate of 370 MSPS. It is housed in a compact 56-pin WQFN package and features a JESD204B interface for high-speed data output. The ADC16DX370RMER is targeted at industries such as communications, radar, and medical imaging, where high precision and dynamic performance are critical.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Resolution | 16 | bits | |
| Sampling Rate | 370 | MSPS | |
| Number of Channels | 2 | Dual-channel | |
| Interface | JESD204B | Subclass 1 | |
| Package | 56-pin WQFN | 8mm x 8mm | |
| Power Supply | 1.2V to 3V | SPI configurable | |
| Input Bandwidth | 1.5 | GHz | |
| Power Consumption | 2.5 | W | Typical |
| Operating Temperature | -40 to +85 | °C |
Key Features
- High-speed sampling at 370 MSPS for rapid data acquisition.
- Dual-channel design supports simultaneous signal processing.
- Integrated input buffers reduce noise and simplify system design.
- JESD204B interface ensures high-speed data transfer with low latency.
- Low-power architecture optimizes energy efficiency in high-performance applications.
Applications
The ADC16DX370RMER is widely used in high-speed data acquisition systems across various industries. In communications, it enables accurate signal processing in wireless and wired networks. In radar systems, it ensures precise data capture for imaging and target detection. In medical imaging, it supports high-resolution signal acquisition for diagnostic equipment. Additionally, it is utilized in test and measurement systems for high-precision signal analysis.
Q & A
What is the sampling rate of the ADC16DX370RMER?
The ADC16DX370RMER operates at a sampling rate of 370 MSPS.
What is the resolution of this ADC?
It offers a resolution of 16 bits.
How many channels does it support?
It supports dual-channel operation.
What interface does it use for data output?
It uses the JESD204B interface for high-speed data transfer.
What is the power consumption of this ADC?
The typical power consumption is 2.5 W.
What is the operating temperature range?
It operates within a temperature range of -40°C to +85°C.
What package does it come in?
It is housed in a 56-pin WQFN package measuring 8mm x 8mm.
Is it configurable via SPI?
Yes, it can be configured using SPI for compatibility with 1.2V to 3V logic circuits.
What industries is this ADC suitable for?
It is suitable for communications, radar, medical imaging, and test and measurement applications.
Does it include integrated input buffers?
Yes, it features integrated input buffers to reduce noise and simplify system design.
