Overview
The ADC1113S125HN-C18 is a high-performance, 11-bit analog-to-digital converter (ADC) produced by Renesas Electronics America Inc. This component is part of the pipelined ADC family and is designed to offer high accuracy and speed, making it suitable for a variety of applications that require precise analog-to-digital conversion.
Key Specifications
| Parameter | Description | Value |
|---|---|---|
| Resolution | Number of bits | 11 bits |
| Sampling Rate | Maximum sampling frequency | 125 MSPS |
| Number of Channels | Single channel | 1 channel |
| Package Type | Package form factor | 56HVQFN |
| Supply Voltage | Operating voltage range | Typically 1.8V or 3.3V |
| Operating Temperature | Temperature range for operation | -40°C to +85°C |
| Interface | Communication interface | Pipelined ADC with various interface options |
Key Features
- High Resolution and Speed: The ADC1113S125HN-C18 offers 11-bit resolution with a maximum sampling rate of 125 MSPS, making it ideal for high-speed data acquisition applications.
- Pipelined Architecture: This ADC uses a pipelined architecture, which provides high throughput and low latency.
- Low Power Consumption: Designed to operate at low power, this ADC is suitable for battery-powered devices and other power-sensitive applications.
- Compact Package: The 56HVQFN package is compact and suitable for space-constrained designs.
- Wide Operating Temperature Range: The component can operate over a wide temperature range, making it versatile for various environmental conditions.
Applications
- Medical Imaging: High-resolution imaging in medical devices such as MRI and CT scanners.
- Industrial Automation: High-speed data acquisition in industrial control systems and sensors.
- Aerospace and Defense: Applications requiring high accuracy and reliability in harsh environments.
- Communications: Baseband processing in wireless communication systems.
- Test and Measurement: High-speed data acquisition in test and measurement equipment.
Q & A
- What is the resolution of the ADC1113S125HN-C18?
The ADC1113S125HN-C18 has a resolution of 11 bits.
- What is the maximum sampling rate of the ADC1113S125HN-C18?
The maximum sampling rate is 125 MSPS.
- What is the package type of the ADC1113S125HN-C18?
The package type is 56HVQFN.
- What is the operating voltage range of the ADC1113S125HN-C18?
The operating voltage range is typically 1.8V or 3.3V.
- What is the operating temperature range of the ADC1113S125HN-C18?
The operating temperature range is -40°C to +85°C.
- What architecture does the ADC1113S125HN-C18 use?
The ADC1113S125HN-C18 uses a pipelined architecture.
