Overview
The ADC0804LCWM-NS is an 8-bit successive approximation register (SAR) analog-to-digital converter (ADC) produced by National Semiconductor. This component is designed to convert analog signals into digital data, making it a crucial element in various data acquisition and signal processing systems. The ADC0804LCWM-NS is known for its high accuracy, reliability, and compatibility with a wide range of applications.
Key Specifications
| Parameter | Value |
|---|---|
| Resolution | 8 bits |
| Conversion Method | Successive Approximation Register (SAR) |
| Package Type | 20-pin SOIC (Small Outline Integrated Circuit) |
| Operating Voltage | 5V |
| Operating Temperature Range | -40°C to 85°C |
| Conversion Time | Typically 100 μs |
| Interface | Compatible with most microprocessors and microcontrollers |
Key Features
- High accuracy and linearity in analog-to-digital conversion.
- Low power consumption, making it suitable for battery-powered devices.
- Compact 20-pin SOIC package for space-efficient designs.
- Wide operating temperature range (-40°C to 85°C) for use in various environmental conditions.
- Compatibility with most microprocessors and microcontrollers for easy integration into existing systems.
Applications
The ADC0804LCWM-NS is versatile and can be used in a variety of applications, including:
- Data acquisition systems for industrial, medical, and automotive sectors.
- Signal processing and measurement instruments.
- Embedded systems and IoT devices requiring analog-to-digital conversion.
- Automated control systems and robotics.
Q & A
- What is the resolution of the ADC0804LCWM-NS?
The ADC0804LCWM-NS has an 8-bit resolution. - What is the conversion method used by the ADC0804LCWM-NS?
The ADC0804LCWM-NS uses the Successive Approximation Register (SAR) method. - What is the package type of the ADC0804LCWM-NS?
The ADC0804LCWM-NS comes in a 20-pin SOIC package. - What is the operating voltage of the ADC0804LCWM-NS?
The operating voltage of the ADC0804LCWM-NS is 5V. - What is the operating temperature range of the ADC0804LCWM-NS?
The operating temperature range is -40°C to 85°C. - How long does the conversion process typically take for the ADC0804LCWM-NS?
The conversion time is typically 100 μs. - Is the ADC0804LCWM-NS compatible with most microprocessors and microcontrollers?
Yes, it is compatible with most microprocessors and microcontrollers. - What are some common applications of the ADC0804LCWM-NS?
Common applications include data acquisition systems, signal processing instruments, embedded systems, and automated control systems. - What is the typical power consumption of the ADC0804LCWM-NS?
The ADC0804LCWM-NS has low power consumption, making it suitable for battery-powered devices. - Where can I find detailed specifications and datasheets for the ADC0804LCWM-NS?
Detailed specifications and datasheets can be found on the official National Semiconductor website or through authorized distributors like Digi-Key, Mouser, and Arrow Electronics.
