Overview
The S9S08SG8E2CTGR,534 is an 8-bit microcontroller from NXP USA Inc., part of the S08SG family. This microcontroller is designed for a range of applications, including LIN follower, general market, and high-temperature environments. It is an entry-level to mid-range MCU, offering a balance of performance and cost-effectiveness.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | S9S08SG8E2CTGR,534 |
| Manufacturer | NXP USA Inc. |
| Microcontroller Type | 8-bit |
| Family | S08SG |
| Flash Memory | 8 KB |
| Package Type | 16-TSSOP |
| Operating Frequency | Up to 40 MHz |
| Operating Temperature | -40°C to 125°C |
| Supply Voltage | 2.7V to 5.5V |
Key Features
- 8-bit HCS08 Central Processing Unit (CPU)
- 8 KB of Flash memory
- 768 bytes of RAM
- Integrated LIN (Local Interconnect Network) interface
- High-temperature operation capability
- Low power consumption
- On-chip oscillator and clock generator
- Various peripheral interfaces including SCI, SPI, and I2C
Applications
The S9S08SG8E2CTGR,534 microcontroller is suitable for a variety of applications, including:
- LIN follower and automotive systems
- General market applications requiring cost-effective and reliable performance
- High-temperature environments such as industrial control systems and automotive electronics
- Consumer electronics and appliances
- Automotive body electronics and control systems
Q & A
- What is the S9S08SG8E2CTGR,534 microcontroller used for? It is used in various applications including LIN follower, general market, and high-temperature environments.
- What is the flash memory size of the S9S08SG8E2CTGR,534? The flash memory size is 8 KB.
- What is the package type of the S9S08SG8E2CTGR,534? It comes in a 16-TSSOP package.
- What is the operating frequency of the S9S08SG8E2CTGR,534? It operates up to 40 MHz.
- What is the operating temperature range of the S9S08SG8E2CTGR,534? The operating temperature range is -40°C to 125°C.
- Does the S9S08SG8E2CTGR,534 support LIN interface? Yes, it supports LIN (Local Interconnect Network) interface.
- What are the supply voltage requirements for the S9S08SG8E2CTGR,534? The supply voltage range is 2.7V to 5.5V.
- Is the S9S08SG8E2CTGR,534 suitable for high-temperature applications? Yes, it is designed for high-temperature environments.
- What peripherals does the S9S08SG8E2CTGR,534 support? It supports various peripherals including SCI, SPI, and I2C.
- Where can I find more detailed specifications for the S9S08SG8E2CTGR,534? You can find detailed specifications on the NXP Semiconductors official website or through authorized distributors like Mouser and Digi-Key.
