Overview
The S9S08AW16AE0MLDR is a 8-bit microcontroller from NXP USA Inc., part of the HCS08 family. This microcontroller is designed to provide a robust and versatile solution for a wide range of applications, including industrial control, automotive systems, and consumer electronics. It features a high-performance CPU, various peripheral modules, and advanced power management capabilities.
Key Specifications
| Specification | Details |
|---|---|
| Microcontroller Type | 8-bit HCS08 |
| Package Type | LQFP44 (Low Profile Quad Flat Package, 44 terminals) |
| Package Dimensions | 10 mm x 10 mm x 1.4 mm, 0.8 mm pitch |
| Flash Memory | 16 KB |
| RAM | 1 KB |
| EEPROM | 512 bytes |
| CPU Speed | Up to 20 MHz |
| Timer/PWM Modules | 16-bit timer/pulse-width modulator (TPM) with selectable input capture, output compare, and edge-aligned PWM capability |
| I/O Pins | Up to 54 general-purpose input/output (I/O) pins |
| Power Supply | 2.7V to 5.5V |
| Operating Temperature | -40°C to 85°C |
Key Features
- High-performance 8-bit HCS08 CPU
- Advanced power management with low power modes and wake-up on interrupt
- 16-bit timer/pulse-width modulator (TPM) with buffered, centered PWM (CPWM) capability
- Up to 54 general-purpose input/output (I/O) pins with software-selectable pullups, slew rate control, and drive strength
- Keyboard interrupt module (KBI) with up to 8-pin support
- Internal pullup on RESET, IRQ, and BKGD/MS pins
- Master reset pin and power-on reset (POR)
Applications
The S9S08AW16AE0MLDR microcontroller is suitable for various applications, including:
- Industrial control systems
- Automotive systems (e.g., dashboard controls, sensors)
- Consumer electronics (e.g., appliances, remote controls)
- Medical devices
- IoT devices and smart home systems
Q & A
- What is the CPU type of the S9S08AW16AE0MLDR microcontroller?
The S9S08AW16AE0MLDR features an 8-bit HCS08 CPU. - What is the package type and dimensions of the S9S08AW16AE0MLDR?
The package type is LQFP44, with dimensions of 10 mm x 10 mm x 1.4 mm and a 0.8 mm pitch. - How much flash memory does the S9S08AW16AE0MLDR have?
The S9S08AW16AE0MLDR has 16 KB of flash memory. - What are the key features of the TPM module in the S9S08AW16AE0MLDR?
The TPM module features 16-bit timer/pulse-width modulator capabilities with selectable input capture, output compare, and edge-aligned PWM capability. - How many general-purpose I/O pins does the S9S08AW16AE0MLDR have?
The S9S08AW16AE0MLDR has up to 54 general-purpose input/output (I/O) pins. - What is the operating voltage range of the S9S08AW16AE0MLDR?
The operating voltage range is 2.7V to 5.5V. - What are the temperature operating ranges for the S9S08AW16AE0MLDR?
The operating temperature range is -40°C to 85°C. - Does the S9S08AW16AE0MLDR support keyboard interrupt?
Yes, it supports up to 8-pin keyboard interrupt (KBI). - What power management features does the S9S08AW16AE0MLDR have?
The microcontroller features advanced power management with low power modes and wake-up on interrupt. - What are some common applications of the S9S08AW16AE0MLDR?
Common applications include industrial control systems, automotive systems, consumer electronics, medical devices, and IoT devices.
