Overview
The S912ZVC12F0VLFR,528 is a 16-bit microcontroller from NXP USA Inc., part of the MagniV S12Z series. This microcontroller is designed for automotive and industrial applications, offering a robust set of features and specifications that make it suitable for demanding environments. With its S12Z core, the device provides high performance and reliability.
Key Specifications
| Specification | Value |
|---|---|
| Core Processor | S12Z |
| Speed | 32 MHz |
| Program Memory Size | 128 KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 2K x 8 |
| RAM Size | 8K x 8 |
| Number of I/O | 28 |
| Operating Temperature Range | -40°C to +105°C |
| Voltage Supply (Vcc/Vdd) | 3.5V ~ 40V |
| Package Type | LQFP48 (plastic, low profile quad flat package) |
| Data Converters | A/D 10x10b; D/A 1x8b |
| Connectivity | CAN, I²C, SCI, SPI |
| Peripherals | DMA, POR, PWM, WDT |
Key Features
- S12Z Core Processor: Provides high performance and reliability.
- 32 MHz Speed: Ensures efficient processing for various applications.
- 128 KB Flash Memory: Ample program memory for complex applications.
- CAN, I²C, SCI, SPI Connectivity: Supports multiple communication protocols.
- DMA, POR, PWM, WDT Peripherals: Includes a range of peripherals for enhanced functionality.
- A/D and D/A Converters: Features 10-bit A/D and 8-bit D/A converters for analog signal processing.
- Automotive Qualified: Meets stringent automotive standards for reliability and performance.
Applications
The S912ZVC12F0VLFR,528 microcontroller is primarily used in automotive and industrial applications. It is suitable for:
- Automotive Systems: Engine control, transmission control, and other vehicle systems.
- Industrial Control: Motor control, power management, and automation systems.
- Embedded Systems: Various embedded applications requiring high reliability and performance.
Q & A
- What is the core processor of the S912ZVC12F0VLFR,528?
The core processor is the S12Z. - What is the operating speed of the microcontroller?
The operating speed is 32 MHz. - How much program memory does the microcontroller have?
The microcontroller has 128 KB of Flash memory. - What is the operating temperature range of the microcontroller?
The operating temperature range is -40°C to +105°C. - What types of connectivity does the microcontroller support?
The microcontroller supports CAN, I²C, SCI, and SPI connectivity. - What peripherals are included in the microcontroller?
The peripherals include DMA, POR, PWM, and WDT. - Is the microcontroller automotive qualified?
Yes, the microcontroller is automotive qualified. - What is the package type of the microcontroller?
The package type is LQFP48 (plastic, low profile quad flat package). - What are the data converters available in the microcontroller?
The microcontroller features 10-bit A/D and 8-bit D/A converters. - What is the voltage supply range for the microcontroller?
The voltage supply range is 3.5V ~ 40V.
