Overview
The PXAG30KBA,512 is a 16-bit microcontroller from NXP Semiconductors, part of the XA microcontroller family. This device is designed to be highly versatile and reliable, making it suitable for a wide range of electronic projects. It combines a central processing unit (CPU), memory, input/output peripherals, and programmable input/output pins, acting as the core component in embedded systems. The microcontroller is known for its small size, low power consumption, easy integration, and strong programmability, which are key advantages in modern electronic design.
Key Specifications
| Parameter | Specification |
|---|---|
| Microcontroller Type | 16-bit |
| Program and Data Address Range | 24-bit |
| RAM | 512 bytes |
| UARTs | 2 |
| Watchdog | Yes |
| Operating Voltage | 2.7 V to 5.5 V |
| Operating Temperature | 0°C to 70°C (TA) |
| Package Type | PLCC-68 |
| Clock Speed | Up to 30 MHz |
| RoHS Status | Lead Free / RoHS Compliant |
Key Features
- Advanced CPU Architecture: The PXAG30KBA features an XA 16-bit microcontroller with a 24-bit program and data address range, and eight 16-bit CPU registers capable of performing all arithmetic and logic operations.
- Memory and Storage: It includes 512 bytes of on-chip data RAM and supports external memory interfaces such as EBI/EMI and I²C.
- Communication Interfaces: The microcontroller is equipped with two UARTs (Universal Asynchronous Receiver-Transmitters) for serial communication.
- Watchdog Timer: A built-in watchdog timer ensures system reliability by monitoring and resetting the system if it enters an invalid state.
- Peripheral Support: It supports various peripherals including PWM (Pulse Width Modulation), timers/counters, and baud rate generators.
- Power and Operating Conditions: The device operates within a voltage range of 2.7 V to 5.5 V and an operating temperature range of 0°C to 70°C, ensuring flexibility and reliability in different environments.
Applications
- Robots: Suitable for robotic systems due to its advanced processing capabilities and peripheral support.
- Smart Home: Used in smart home devices for automation and control.
- Automotive Electronics: Applied in various automotive systems requiring robust and reliable microcontrollers.
- Medical Equipment: Utilized in medical devices where precision and reliability are critical.
- Aerospace: Employed in aerospace applications due to its high performance and reliability.
- Intelligent Instruments: Used in intelligent instruments and embedded systems.
- Industrial Automation: Applied in industrial automation for control and monitoring purposes.
Q & A
- What is the PXAG30KBA,512 microcontroller's CPU architecture?
The PXAG30KBA,512 features a 16-bit CPU with a 24-bit program and data address range and eight 16-bit CPU registers.
- How much RAM does the PXAG30KBA,512 have?
The device includes 512 bytes of on-chip data RAM.
- What communication interfaces does the PXAG30KBA,512 support?
The microcontroller supports two UARTs and other interfaces like EBI/EMI and I²C.
- What is the operating voltage range of the PXAG30KBA,512?
The device operates within a voltage range of 2.7 V to 5.5 V.
- What is the maximum clock speed of the PXAG30KBA,512?
The clock speed can go up to 30 MHz.
- Is the PXAG30KBA,512 RoHS compliant?
Yes, the device is Lead Free / RoHS Compliant.
- What package type is the PXAG30KBA,512 available in?
The device is available in a PLCC-68 package.
- What are some common applications of the PXAG30KBA,512?
It is used in robots, smart home devices, automotive electronics, medical equipment, aerospace, intelligent instruments, and industrial automation.
- Does the PXAG30KBA,512 have a watchdog timer?
Yes, the device includes a built-in watchdog timer.
- What is the operating temperature range of the PXAG30KBA,512?
The operating temperature range is 0°C to 70°C (TA).
