Overview
The LPC812M101JDH16 is a 32-bit microcontroller from NXP USA Inc., part of the LPC81x family. It is based on the ARM Cortex-M0+ core and is designed to provide a balance of value and integration, making it an ideal choice for entry-level and 8-bit alternative MCU applications. This microcontroller is supported by the MCUXpresso development environment and is known for its low power consumption and versatile peripheral set.
Key Specifications
| Parameter | Value |
|---|---|
| Microcontroller Core | ARM Cortex-M0+ |
| Flash Memory | 16 KB |
| SRAM | 4 KB |
| USART | Up to 3 |
| I2C-bus Interface | 1 |
| SPI Interfaces | Up to 2 |
| Comparator | 1 |
| GPIO | 18 |
| Package Type | TSSOP20 |
| Operating Temperature Range | -40 °C to 105 °C |
| Power Modes | Sleep, Deep-sleep, Power-down, Deep power-down |
Key Features
- Integrated Power Management Unit (PMU) to minimize power consumption
- Reduced power modes: Sleep, Deep-sleep, Power-down, and Deep power-down
- Wake-up from Deep-sleep and Power-down modes on activity on USART, SPI, and I2C peripherals
- Timer-controlled self wake-up from Deep power-down mode
- Power-On Reset (POR) and Brownout detect
- Unique device serial number for identification
- Serial Wire Debug (SWD) and JTAG boundary scan modes supported
- Nested Vectored Interrupt Controller (NVIC) and system tick timer
Applications
- 8/16-bit applications
- Lighting
- Consumer electronics
- Motor control
- Climate control
- Fire and security applications
Q & A
- What is the core architecture of the LPC812M101JDH16?
The LPC812M101JDH16 is based on the ARM Cortex-M0+ core. - How much flash memory does the LPC812M101JDH16 have?
The LPC812M101JDH16 has 16 KB of flash memory. - What are the power modes available on the LPC812M101JDH16?
The available power modes are Sleep, Deep-sleep, Power-down, and Deep power-down. - Does the LPC812M101JDH16 support wake-up from low power modes?
Yes, it supports wake-up from Deep-sleep and Power-down modes on activity on USART, SPI, and I2C peripherals. - What is the operating temperature range of the LPC812M101JDH16?
The operating temperature range is -40 °C to 105 °C. - What package types are available for the LPC812M101JDH16?
The LPC812M101JDH16 is available in TSSOP20 package. - Does the LPC812M101JDH16 have a unique device serial number?
Yes, it has a unique device serial number for identification. - What debug modes are supported by the LPC812M101JDH16?
The LPC812M101JDH16 supports Serial Wire Debug (SWD) and JTAG boundary scan modes. - What are some typical applications of the LPC812M101JDH16?
Typical applications include 8/16-bit applications, lighting, consumer electronics, motor control, climate control, and fire and security applications. - Is the LPC812M101JDH16 RoHS compliant?
Yes, the LPC812M101JDH16 is RoHS compliant.
