Overview
The LPC4320FET100 is a 32-bit dual-core microcontroller from NXP Semiconductors, featuring ARM Cortex-M4 and Cortex-M0 cores. This microcontroller is designed for high-performance and energy-efficient embedded applications. It operates at frequencies up to 204 MHz and includes a rich set of peripherals, making it versatile for various connectivity and control requirements. The ROMless design offers flexibility for customized firmware, and the device is optimized for low power consumption, making it suitable for battery-powered devices.
Key Specifications
| Parameter | Value |
|---|---|
| Manufacturer | NXP Semiconductors |
| Manufacturer Part Number | LPC4320FET100 |
| Core Type | 32-bit ARM Cortex-M4/M0 |
| Operating Frequency | Up to 204 MHz |
| SRAM | 200 KB |
| Package | 100-TFBGA (9x9) |
| Supply Voltage | 2.2V to 3.6V |
| Operating Temperature | -40°C to 85°C |
| Number of I/Os | 49 |
| USB Controllers | 1 (High-Speed, Host/Device) |
| CAN | 2 |
| UART | 4 |
| SPI | 3 |
| ADC (Channels) | 2 (10-bit, 400 ksps) |
Key Features
- Dual-core architecture with ARM Cortex-M4 and Cortex-M0 cores operating at up to 204 MHz
- Extensive peripheral set including CAN, Ethernet, USB, SPI, UART, and more
- Integrated power management and clock control
- Low power consumption modes for optimized energy efficiency
- ROMless design for customized firmware
- Brown-out detection and reset, power-on reset, and watchdog timer for system reliability
- Compliant with ROHS directive
Applications
- Industrial automation and control
- Automotive electronics
- Medical devices
- Consumer electronics
- Telecommunications equipment
Q & A
- What is the core architecture of the LPC4320FET100?
The LPC4320FET100 features a 32-bit dual-core architecture with ARM Cortex-M4 and Cortex-M0 cores.
- What is the maximum operating frequency of the LPC4320FET100?
The maximum operating frequency is up to 204 MHz.
- How much SRAM does the LPC4320FET100 have?
The LPC4320FET100 has 200 KB of on-chip SRAM.
- What is the package type of the LPC4320FET100?
The package type is 100-TFBGA (9x9).
- What is the supply voltage range for the LPC4320FET100?
The supply voltage range is from 2.2V to 3.6V.
- What are some of the key peripherals included in the LPC4320FET100?
The key peripherals include CAN, Ethernet, USB, SPI, UART, and ADC.
- Is the LPC4320FET100 ROHS compliant?
- What are the typical applications of the LPC4320FET100?
- Does the LPC4320FET100 have any built-in safety features?
- What is the operating temperature range of the LPC4320FET100?
