Overview
The BZX284-C4V7,115 is a voltage regulator diode produced by NXP USA Inc. This component is part of the BZX284 series, which is designed to provide stable voltage regulation in various electronic circuits. The BZX284-C4V7,115 is specifically rated for a nominal zener voltage of 4.7V and is encapsulated in a SOD110 package, making it suitable for a wide range of applications requiring voltage stabilization.
Key Specifications
| Parameter | Value |
|---|---|
| Nominal Zener Voltage | 4.7V |
| Maximum Power Dissipation | 400mW |
| Package Type | SOD110 |
| Operating Temperature Range | -65°C to +150°C |
| Maximum Reverse Current | 5μA (at V_R = 3.5V, T_j = 25°C) |
Key Features
- Stable voltage regulation with a nominal zener voltage of 4.7V.
- High power dissipation capability of up to 400mW.
- Compact SOD110 package suitable for space-constrained designs.
- Wide operating temperature range from -65°C to +150°C.
- Low reverse current, ensuring minimal leakage and efficient operation.
Applications
The BZX284-C4V7,115 is versatile and can be used in various applications requiring stable voltage regulation, such as:
- Voltage stabilization in power supplies and voltage regulators.
- Overvoltage protection circuits.
- Signal clipping and clamping circuits.
- Audio and video equipment.
- Automotive and industrial control systems.
