Overview
The BZX284-C24,115 is a zener diode produced by NXP USA Inc., now part of Nexperia. This component is designed to regulate voltage and provide protection against voltage spikes in electronic circuits. Although the BZX284-C24,115 is currently listed as obsolete and no longer manufactured, it remains relevant for legacy systems and can be substituted with similar zener diodes if necessary.
Key Specifications
| Parameter | Value |
|---|---|
| Voltage (V_Z) | 24V |
| Tolerance | 5% |
| Power Dissipation (P_D) | 400mW |
| Impedance (Z_ZT) | 30Ω |
| Package | SOD110 (2-pin) |
| Temperature Range | -65°C to 150°C |
Key Features
- Single zener diode configuration for voltage regulation.
- Low impedance (Z_ZT) of 30Ω for stable voltage regulation.
- High power dissipation of 400mW, suitable for various applications.
- Compact SOD110 package, ideal for space-constrained designs.
- Wide operating temperature range from -65°C to 150°C.
Applications
The BZX284-C24,115 zener diode is commonly used in various electronic circuits for voltage regulation, surge protection, and voltage clamping. It is suitable for applications such as:
- Voltage regulators and power supplies.
- Surge protectors and overvoltage protection circuits.
- Audio and signal processing circuits requiring stable voltage references.
- Automotive and industrial control systems where robust voltage regulation is necessary.
Q & A
- What is the primary function of the BZX284-C24,115? The primary function is to regulate voltage and provide protection against voltage spikes.
- What is the voltage rating of the BZX284-C24,115? The voltage rating is 24V with a 5% tolerance.
- What is the power dissipation capacity of the BZX284-C24,115? The power dissipation capacity is 400mW.
- What package type does the BZX284-C24,115 come in? It comes in a SOD110 (2-pin) package.
- Is the BZX284-C24,115 still in production? No, it is currently listed as obsolete and no longer manufactured.
- What are some common applications for the BZX284-C24,115? Common applications include voltage regulators, surge protectors, audio circuits, and automotive/industrial control systems.
- What is the impedance of the BZX284-C24,115? The impedance (Z_ZT) is 30Ω.
- What is the operating temperature range of the BZX284-C24,115? The operating temperature range is from -65°C to 150°C.
- Where can I find detailed specifications for the BZX284-C24,115? Detailed specifications can be found in the datasheet available from sources like Nexperia, Digi-Key, and other electronic component distributors.
- Can I substitute the BZX284-C24,115 with another component if it is no longer available? Yes, you can substitute it with similar zener diodes that match its specifications.
