Overview
The ADC0808S125HW/C1,1 is an 8-bit analog-to-digital converter (ADC) manufactured by NXP USA Inc. This component is part of the ADC0808 series and is designed for high-speed conversion applications. It features a single-channel, differential input and operates at a sampling rate of 125 million samples per second. The ADC is housed in a 48-HTQFP (7x7) package with an exposed pad, making it suitable for surface mount applications.
Although the ADC0808S125HW/C1,1 is currently listed as obsolete and no longer manufactured, it remains available from various distributors and inventory holders.
Key Specifications
| Parameter | Value |
|---|---|
| Manufacturer | NXP USA Inc. |
| Part Number | ADC0808S125HW/C1,1 |
| Description | ADC 8BIT SGL 125MHZ 48HTQFP |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 125M |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 3V ~ 3.6V |
| Voltage - Supply, Digital | 1.65V ~ 1.95V |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 48-TQFP Exposed Pad |
| Supplier Device Package | 48-HTQFP (7x7) |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) or 3 (168 Hours) |
Key Features
- High-Speed Conversion: The ADC0808S125HW/C1,1 operates at a sampling rate of 125 million samples per second, making it suitable for high-speed data acquisition applications.
- Differential Input: It features a single-channel differential input, which enhances signal-to-noise ratio and reduces common-mode noise.
- Parallel Data Interface: The ADC provides a parallel data interface, facilitating easy integration with microprocessors and other digital systems.
- Sample and Hold (S/H) Configuration: The component includes a built-in sample and hold circuit, ensuring accurate conversion of the analog signal.
- External/Internal Reference: It supports both external and internal reference voltage options, offering flexibility in system design.
- Low Power Consumption: The ADC operates with low power consumption, with analog and digital supply voltages ranging from 3V to 3.6V and 1.65V to 1.95V, respectively.
- Wide Operating Temperature Range: The component is designed to operate over a wide temperature range of -40°C to 85°C, making it suitable for various environmental conditions.
Applications
- High-Speed Data Acquisition Systems: The ADC0808S125HW/C1,1 is ideal for applications requiring fast and accurate analog-to-digital conversion, such as in medical imaging, radar systems, and high-speed test and measurement equipment.
- Industrial Automation: It can be used in industrial automation systems for real-time monitoring and control of analog signals.
- Aerospace and Defense: The component's robust design and wide operating temperature range make it suitable for use in aerospace and defense applications.
- Telecommunications: It can be employed in telecommunications equipment for signal processing and data transmission.
Q & A
- What is the sampling rate of the ADC0808S125HW/C1,1?
The sampling rate of the ADC0808S125HW/C1,1 is 125 million samples per second.
- What type of input does the ADC0808S125HW/C1,1 have?
The ADC0808S125HW/C1,1 has a single-channel differential input.
- What is the data interface type of the ADC0808S125HW/C1,1?
The ADC0808S125HW/C1,1 features a parallel data interface.
- What are the supply voltage ranges for the ADC0808S125HW/C1,1?
The analog supply voltage range is 3V to 3.6V, and the digital supply voltage range is 1.65V to 1.95V.
- Is the ADC0808S125HW/C1,1 RoHS compliant?
Yes, the ADC0808S125HW/C1,1 is ROHS3 compliant.
- What is the operating temperature range of the ADC0808S125HW/C1,1?
The operating temperature range is -40°C to 85°C.
- What is the package type of the ADC0808S125HW/C1,1?
The ADC0808S125HW/C1,1 is housed in a 48-HTQFP (7x7) package with an exposed pad.
- Is the ADC0808S125HW/C1,1 still in production?
No, the ADC0808S125HW/C1,1 is currently listed as obsolete and no longer manufactured.
- Where can I find the datasheet for the ADC0808S125HW/C1,1?
The datasheet can be downloaded from various distributor websites such as Z.H.T TECHNOLOGY HK LIMITED, Ariat-Tech Electronics, and Digi-Key.
- What are some typical applications for the ADC0808S125HW/C1,1?
Typical applications include high-speed data acquisition systems, industrial automation, aerospace and defense, and telecommunications.
