Overview
The 74HC2G32DP-Q100H is a dual 2-input OR gate integrated circuit produced by Nexperia USA Inc. This component is part of the 74HC family, known for its high-speed CMOS logic and is specifically designed for automotive and industrial applications. It is qualified to the AEC-Q100 standard, ensuring reliability and performance in harsh environments.
Key Specifications
| Parameter | Value |
|---|---|
| Package Type | 8-TSSOP (Thin Shrink Small Outline Package) |
| Logic Type | OR Gate, 2-input |
| Number of Gates | 2 |
| Supply Voltage | 2 V to 6 V |
| Operating Temperature | -40°C to +125°C |
| Input Type | CMOS |
| Output Type | Push-Pull |
| Output Current | 5.2 mA (high and low) |
| Qualification Standard | AEC-Q100 (Grade 1) |
Key Features
- High-speed CMOS logic with low power consumption.
- Dual 2-input OR gates in a single package, enhancing design flexibility.
- Wide operating temperature range from -40°C to +125°C, making it suitable for harsh environments.
- Qualified to AEC-Q100 standard, ensuring automotive-grade reliability.
- Compact 8-TSSOP package, ideal for space-constrained designs.
Applications
- Automotive electronics: Suitable for various automotive applications due to its AEC-Q100 qualification, including safety and efficiency enhancements in e-mobility options.
- Industrial automation: Used in industrial environments for applications such as motor drives, collaborative robots (cobots), and industrial equipment.
- Consumer electronics: Can be used in general-purpose logic circuits where high speed and low power consumption are required.
Q & A
- What is the package type of the 74HC2G32DP-Q100H? The package type is 8-TSSOP (Thin Shrink Small Outline Package).
- What is the logic function of this IC? It is a dual 2-input OR gate.
- What is the operating temperature range of this component? The operating temperature range is from -40°C to +125°C.
- Is this component qualified for automotive use? Yes, it is qualified to the AEC-Q100 standard.
- What is the supply voltage range for this IC? The supply voltage range is from 2 V to 6 V.
- What is the output current capability of this IC? The output current is 5.2 mA (both high and low).
- In what types of applications is this IC commonly used? It is commonly used in automotive electronics, industrial automation, and general-purpose logic circuits.
- What is the advantage of using CMOS logic in this IC? CMOS logic offers high speed and low power consumption.
- How many gates are included in this IC? This IC includes two 2-input OR gates.
- What is the significance of AEC-Q100 qualification? AEC-Q100 qualification ensures that the component meets stringent automotive reliability standards.
