Overview
The MAX1122BEGK is a high-performance, 10-bit analog-to-digital converter (ADC) produced by Analog Devices Inc./Maxim Integrated. This pipelined ADC is designed for high-speed data acquisition applications, offering a sampling rate of 170 million samples per second (Msps). The device features a single-channel differential input and a parallel LVDS data interface, making it suitable for a variety of high-speed data conversion needs.
Key Specifications
| Parameter | Value |
|---|---|
| Number of Bits | 10 |
| Sampling Rate | 170 Msps |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | LVDS - Parallel |
| Number of Pins | 68 |
| Package Type | QFN |
Key Features
- High-speed sampling rate of 170 Msps
- 10-bit resolution with pipelined architecture
- Single-channel differential input
- Parallel LVDS data interface for high-speed data transfer
- 68-pin QFN package for compact design
Applications
The MAX1122BEGK is ideal for various high-speed data acquisition applications, including:
- Medical imaging and diagnostics
- Radar and surveillance systems
- High-speed data acquisition in scientific instruments
- Communication systems requiring high-speed ADCs
Q & A
- What is the resolution of the MAX1122BEGK ADC?
The MAX1122BEGK has a resolution of 10 bits. - What is the sampling rate of the MAX1122BEGK?
The sampling rate is 170 million samples per second (Msps). - How many analog inputs does the MAX1122BEGK have?
The MAX1122BEGK has one analog input. - What type of input does the MAX1122BEGK support?
The MAX1122BEGK supports differential inputs. - What is the data interface type of the MAX1122BEGK?
The data interface is LVDS - Parallel. - How many pins does the MAX1122BEGK have?
The MAX1122BEGK has 68 pins. - What is the package type of the MAX1122BEGK?
The package type is QFN (Quad Flat No-Lead). - What are some typical applications of the MAX1122BEGK?
Typical applications include medical imaging, radar and surveillance systems, high-speed data acquisition in scientific instruments, and communication systems. - Is the MAX1122BEGK suitable for high-speed data conversion?
Yes, the MAX1122BEGK is designed for high-speed data conversion applications. - Where can I find detailed specifications for the MAX1122BEGK?
Detailed specifications can be found on the official Analog Devices website, as well as on distributor websites like Digi-Key and Mouser.
